Equal material : B127, ASME SB-127, AMS 4554, JIS NW4400 , UNS N04400, NiCu30Fe W-Nr: 2.4360, BS NA 12
MCu-28-1.5-1.8 alloy is a kind of corrosion resistance of nickel copper alloy, its organization into a single phase high strength of solid solution. Having excellent corrosion resistance in hydrofluoric acid and fluorine gas medium; also have excellent corrosion resistance to hot concentrated alkaline solution; at the same time also resistant to neutral solution, halogen, high temperature, water, sea water, all kinds of food, a variety of organic compounds in atmospheric corrosion. Generally no stress corrosion crack, good cutting performance.
MCu-28-1.5-1.8 alloy chemical composition
|
|
Ni
|
Fe
|
C
|
Mn
|
Si
|
Cu
|
Al
|
S
|
|
Min
|
63
|
|
|
|
|
28
|
|
|
|
Max
|
|
2.5
|
0.3
|
2.00
|
0.5
|
34
|
0.5
|
0.024
|
MCu-28-1.5-1.8 alloy mechanical property
|
Alloy and state
|
Strength of extension
Rm N/mm2 |
Yield strength
RP0.2N/mm2 |
ductility
A5 % |
|
MCu-28-1.5-1.8
|
480
|
170
|
35
|
MCu-28-1.5-1.8 physical properties
MCu-28-1.5-1.8 density : 8.83 g/cm3
MCu-28-1.5-1.8 alloy Common product forms and specifications
MCu-28-1.5-1.8 alloy bar diameter 11-300mm Rolled or forged
MCu-28-1.5-1.8 alloy Disc Rolled or forged diameter 100-2000mm
MCu-28-1.5-1.8 alloy cold draw diameter 6-75mm Cold drawn
Ring diameter 1000mm Conventional products, large-scale.
Strip 0.15-22 mm thickness cold rolled or hot rolled
MCu-28-1.5-1.8 alloy wire diameter 0.1--9 mm
MCu-28-1.5-1.8 alloy pipe metre OD 6-219mm *0.1-40 mm a variety of cold-rolled, cold drawn pipe
MCu-28-1.5-1.8 executive standard
tube stock: ASME SB163/ B165
Bar: ASME SB164
Board: ASME SB127
MCu-28-1.5-1.8 alloy material chief application
MCu-28-1.5-1.8 alloy products mainly used in marine heat exchangers, seawater desalination equipment, production equipment, the sea salt and chemical processing equipment, the propeller shaft and water pump, gasoline and water tank, chemical, petrochemical, oil, nuclear industry, salt chemical industry, electronic industry and other fields.
