Hastelloy G-3 Machinability

Hastelloy G-3 Machinability

Conventional machining techniques Hastelloy G-3 used for iron based alloys may be used. Machining characteristics are somewhat similar to those for the austenitic (300 Series) stainless steels. Hastelloy G-3 alloy does work-harden during machining and has higher strength and "gumminess" not typical of steels. Hastelloy G-3 Heavy duty machining equipment and tooling should be used to minimize chatter or work-hardening of the alloy ahead of the cutting. Water-base coolants of premium quality are preferred. Hastelloy G-3 Rigid mounting of tooling and the workpiece are important to avoid "chatter" (work hardening ahead of the cut). Both carbide tools and high-speed tools may be used successfully. Hastelloy G-3 Carbide tooling generally permits twice, or better, the feed rate of high-speed tooling for the same depth of cut or drilling.

Hastelloy G-3 Turning: For roughing cuts the tools should have -5 degree back rake for carbide and -10 degree back rake for high-speed steel. Normal and/or finish turning call for positive rake angles of about +10 degrees for both carbide and hig-speed cutters. Cutting speeds and feeds are in the following ranges: For High-Speed Steel Tools For Carbide Tooling Depth Surface Feed Depth Surface Feed of cut speed in inches of cut speed in inches inches feet/min. per rev. inches feet/min. per rev. 0.040" 0.040" 0.250" 0.250" Drilling: Steady feed rates must be used to avoid work hardening due to dwelling of the drill on the metal. Rigid set-ups are essential with as short a stub drill as feasible. Conventional high-speed steel drills work well. Feeds vary from 0.001 inch per rev. for holes of less than 1/16" diameter, 0.002 to 0.003 inch per rev. for 1/4" dia., 0.004 to 0.010 inch per rev. for holes of 7/8"diameter. Speeds of 10 to 25 surface feet/minute, are best for drilling.

Hastelloy G-3 Milling: To obtain good accuracy and a smooth finish it is essential to have rigid machines and fixtures and sharp cutting tools. High-speed steel cutters such as M-2 or M-10 work best with cutting speeds of 30 to 50 surface feet per minute and feed of 0.002-0.007 inch per cutting tooth.

Hastelloy G-3Grinding: The alloy should be wet ground and aluminum oxide wheels or belts are preferred.
