Incoloy 800 Super alloy

Incoloy 800 Super alloy

Incoloy 800 alloy equal material: 0Cr20Ni32AlTi, N08811, NCF800, X2NiCrAlTi3220
The content of Cr in Incoloy 800 alloy is usually 15-25%, nickel content was 30-45%, and contains a small amount of aluminum and titanium. Incoloy 800 alloy from high temperature and fast cooling after all in austenitic single area, therefore, the use of state for a single austenite. Chromium content in the alloy has higher and enough nickel content, so there are high resistance to high temperature corrosion resistance, widely used in industry

Incoloy 800 alloy steel chemical composition .

alloy	C max	Mn max	Si max	P max	S max	Cr	Ni	Cu	Ti	Al	Fe
Incoloy 800	0.10	1.50	1.00	0.030	0.015	19.0 -23.0	30.0 -35.0	0.75	0.15 -0.60	0.15 -0.60	37.0 -47.0

Incoloy 800 alloy steel mechanical property

alloy	Tensile strength	Yield strength	elongation A5 %
800	500 MPa	210 MPa	35

Incoloy 800 alloy steel physical property
Incoloy 800 alloy density : 8.0g/cm3
Melting: 1350-1400 degree

Incoloy 800 alloy steel common product form
Incoloy 800 alloy steel Sheet, strip, pipe, forgings, etc.

Incoloy 800 alloy steel application
The chemical industry, the nuclear generator nitric acid cooler, cracking tube, heat exchanger, heat exchange tube
