W.Nr.1.4529 alloy steel

W.Nr.1.4529 alloy steel
W.Nr.1.4529alloy material Equal material :
American brand：UNS N08926
Germany brand：X1NiCrMoCu
British brand：X1NiCrMoCu
France brand：X1NiCrMoCu
W.Nr.1.4529under the conditions of containing halide, and research and development of high chromium molybdenum special stainless steel of high corrosion resistance. Because of its high molybdenum content, so it has a very high resistance to pitting corrosion and crevice corrosion resistance, and can be widely used in harsh conditions such as high temperature, sea water environment. Some cases are comparable to those obtained and harts alloy and titanium plate, high efficiency stainless steel with high corrosion resistance.Acid medium W.Nr.1.4529is suitable for the existence of all kinds of industrial occasions. Due to low carbon content,its also has excellent resistanceto intergranular corrosion. Especially in acid containing halide, W.Nr.1.4529is better than ordinary stainless steel, can be used in the medium containing high concentrations of chloride ion, stress caused by chloride ion corrosion, pitting and crevice corrosion has excellent corrosion resistance.

W.Nr.1.4529 alloy steel Chemical components

W.Nr.1.4529	%	Ni	Cr	Fe	C	Mn	Si	Cu	Mo	N	P	S
	Min	24	19	Balance				0.5	6.0	0.15
	Max	26	21	Balance	0.02	2	0.5	1.5	7.0	0.25	0.03	0.01

W.Nr.1.4529Physical properties:
W.Nr.1.4529alloy steel Density : 8.1 g/cm3
W.Nr.1.4529alloy steel melting point : 1320-1390 degree
W.Nr.1.4529 minimum mechanical properties value at room temperature

Alloy and state	Tensile strength MPa	Yield strength MP	Elongation A5 %
W.Nr.1.4529	650	295	35

W.Nr.1.4529alloy steel features:

1. In the halide medium and acid medium containing H2S has a high resistance to pitting corrosion and crevice corrosion performance

2. In the actual application can effectively resistance to chloride stress corrosion cracking

3. In most of oxidation and reduction environment of various corrosion has excellent corrosion resistance

4. The mechanical properties of the Cronifer 1925 LC - 904 L Alloy has large improvement

5. 18% compared with series of nickel content in alloy metallurgy stability are improved greatly

6. Used in pressure vessel manufacturing related certification (VdTUV - 196 - 400 degree and ASME certification)

W.Nr.1.4529alloy steel application scope of application areas are:

W.Nr.1.4529is a kind of multi-purpose material, can be applied in many fields of industry:

1. The fire control system, water purification systems, hydraulic and perfusion in ocean engineering piping system

2. The cellulose pulp bleaching pool in production

3. The corrosive oil Wells in the polished rod

4. The hose systems in ocean engineering

5. Acidic gas in the production of pipe, joint, air system, etc

6. In the flue gas desulfurization system components

7. Phosphoric acid in the production of the evaporator, heat exchanger, filter, mixer, etc

8. Sulfuric acid separation and the cooling system

9. Concentration and crystallization salt evaporator

10. Use the condensing water cooling water of power plant and pipeline system

11. Container transport corrosive chemicals

12. The use of organic derivatives of acid chloride catalyst production

13. Reverse osmosis desalination plants
