Stainless steel X105CrMo17

Stainless steel X105CrMo17

Stainless steel X105CrMo17

X105CrMo17 equal material : SUS 440C ,UNS 44004, material 1.4125

X105CrMo17 comprehensive description: X105CrMo17 stainless steel with long lasting protection of corrosion resistance is the surface substrate material. It requires no additional system, in order to protect the base metal, the metal itself will continue. Stainlesssteel products to complete its service life. Due to the raw material is 100% recyclable, have focused on processing. In fact, more than 50% of new stainless steel stainless steel scrap from down, thus completed the full life cycle is used again. So, in the project life cycle is stainless steel, is often the most valuable choice.

X105CrMo17 chemical composition


C
Si
Mn
S
P
Cr
Ni
Min
0.95




16.00

Max
1.20
1.00
1.00
0.030
0.035
18.00
0.60

X105CrMo17 Mechanical properties

Tensile strength N/mm2
Elongation δ5 (%)
Hardness
Internal stress N/mm2
560
18 %
250
250

X105CrMo17 heat treatment process
1) annealing, 800 -920 degree slow cooling.
2) quenching, 1010 - 1070 degree oil cooling;
3) tempering, 100 -180 degree cold fast.

X105CrMo17 scope of application
Mainly used in the manufacture of the corrosion environment and no lubrication bearing working parts in strong oxidizing atmosphere. X105CrMo17 has good temperature resistance; high temperature size so can also be used as corrosion resistant high temperature bearing steel. In addition, can also be used to manufacture high quality tools, such as medical scalpel, scissors,nozzle, bearings, etc. X105CrMo17 , is to improve the performance of X105CrMo17steel free cutting steel, used for automatic lathe, as well as ordinary alloy steel by quenching hardening characteristics, thus can be obtained by selecting the brand and heat treatment conditions to wide range of different mechanical properties. X105CrMo17under dynamic load capacity is low.Stainless steel X105CrMo17 can be producedas X105CrMo17 stainless steel plates,X105CrMo17stainless steel bar,X105CrMo17 stainless steel wire, X105CrMo17 stainless steel forging product
