Corrosion resistant alloy Monel K-500

Corrosion resistant alloy Monel K-500
Monel K-500 Equal material : UNS N05500

Monel K-500 Characteristic:
Monel K-500 is also called UNS N05500, and Alloy with 400 identical corrosion resistance, but has higher mechanical strength and hardness. Monel K-500 alloy steel Has good heat resistance and long term stability.

Monel K-500 Corrosion resistant alloy application field :
Mainly used in the manufacture of aviation engine operating temperature at turbine vane and turbine blade under 750 degree ; used for fasteners, spring manufacturing ship pump, valve parts; chemical equipment; papermaking equipment the pulp scraping blade. Monel K-500 alloy can make plates, steel sheet, forging,round steel, alloy wire

Monel K-500 alloy Chemical composition：

	Ni	Fe	C	Mn	Si	Ti	Cu	Al	S
Min	63					0.35	27.0	2.30
Max		2.0	0.25	1.5	0.5	0.85	33.0	3.15	0.01

Monel K-500 physical property ：
Monel K-500 alloy density: 8.05g/cm3
Monel K-500 alloy steel Melting temperature range: 1288-1343 degree

Monel K-500 alloy minimum mechanical properties value at room temperature :

Alloy	Tensile strength MPa	Yield strength MPa	Elongation A5 %
Monel K-500	1100	790	20

Monel K-500 alloy steel apply range：
Aviation, shipbuilding, chemical equipment
