Equal material : Hastelloy B
UNS N10001 Corrosion resistant alloy Characteristic :
1. control of iron and chromium in the lowest content, prevent the generation of β phase Ni4Mo.
2.The excellent corrosion resistance to reduction environment.Sulfuric acid anti medium concentration
3. excellent and many non oxidative acid corrosion.
4 very good resistance to chloride ion reduction to stress corrosion cracking (SCC).
5.Capacity of excellent resistance to various organic acid corrosion.
UNS N10001 alloy Field of application
Especially in the sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid and other industries.For example:
1.manufacturing work under high temperature bolt; gas turbine rotor blades, impeller and other structural parts;
2.rocket engine thrust chamber;Reverse thrust device
3.on the plane;
4.large high pressure vessel;
5.The elastic gas seal, sealing sheet, rubber machinery electric blade.
UNS N10001 alloy Chemical composition:
|
lNi
|
Cr
|
Fe
|
C
|
Mn
|
Si
|
Mo
|
Si
|
Co
|
V
|
P
|
S
|
Min
|
balance
|
|
4.0
|
|
|
|
26
|
|
|
0.2
|
|
|
Max
|
1.0
|
6.0
|
0.05
|
1.0
|
1.0
|
30
|
1.0
|
2.5
|
0.4
|
0.04
|
0.03
|
UNS N10001 alloy steel physici composition:
UNS N10001 alloy density:9.24g/cm
UNS N10001 alloy steel Melting temperature range:1330-1380 degree
UNS N10001 alloy mechanical properties :
Alloy
|
Tensile strength MPa
|
Yield strength MPa
|
elongation
% |
UNS N10001
|
690
|
310
|
40
|
