Equal material : B127, ASME SB-127, AMS 4554, UNS N04400, NiCu30Fe W-Nr: 2.4360, MCu-28-1.5-1.8 , BS NA 12
JIS NW4400 alloy is a kind of corrosion resistance of nickel copper alloy, its organization into a single phase high strength of solid solution. Having excellent corrosion resistance in hydrofluoric acid and fluorine gas medium; also have excellent corrosion resistance to hot concentrated alkaline solution; at the same time also resistant to neutral solution, halogen, high temperature, water, sea water, all kinds of food, a variety of organic compounds in atmospheric corrosion. Generally no stress corrosion crack, good cutting performance.
JIS NW4400 alloy chemical composition:
|
Ni
|
Fe
|
C
|
Mn
|
Si
|
Cu
|
Al
|
S
|
Min
|
63
|
|
|
|
|
28
|
|
|
Max
|
|
2.5
|
0.3
|
2.00
|
0.5
|
34
|
0.5
|
0.024
|
JIS NW4400 alloy mechanical property:
Alloy and state
|
Strength of extension
Rm N/mm2 |
Yield strength
RP0.2N/mm2 |
ductility
A5 % |
UNS N04400
|
480
|
170
|
35
|
JIS NW4400 physical properties:
JIS NW4400 density : 8.83 g/cm3
JIS NW4400alloy Common product forms and specifications
JIS NW4400 alloy bar diameter 11-300mm Rolled or forged
JIS NW4400alloy Disc Rolled or forged diameter 100-2000mm
JIS NW4400 alloy cold draw diameter 6-75mm Cold drawn
Ring diameter 1000mm Conventional products, large-scale.
Strip 0.15-22 mm thickness cold rolled or hot rolled
JIS NW4400alloy wire diameter 0.1--9 mm
JIS NW4400alloy pipe metre OD 6-219mm *0.1-40 mm a variety of cold-rolled, cold drawn pipe
JIS NW4400 executive standard
tube stock: ASME SB163/ B165
Bar: ASME SB164
Board: ASME SB127
JIS NW4400 alloy material chief application:
JIS NW4400 alloy products mainly used in marine heat exchangers, seawater desalination equipment, production equipment, the sea salt and chemical processing equipment, the propeller shaft and water pump, gasoline and water tank, chemical, petrochemical, oil, nuclear industry, salt chemical industry, electronic industry and other fields.
