GH4145 Superalloy alloy steel

GH4145 Superalloy alloy steel

GH4145 alloy mainly γ "[Ni3 (Al, Ti, Nb)] with aging strengthened nickel-base superalloy, below 980 ℃ with good resistance to corrosion and oxidation resistance below 800 ℃ with high strength, below 540 ℃ has good resistance to relaxation properties, but also has good formability and weldability. the alloy is mainly used in the manufacture of aviation engines work below 800 ℃ and require higher strength and resistance to relaxation of the flat spring coil spring. can also be used in the manufacture of gas turbine turbine blades and other parts. can supply a variety of sheet, strip, bar, forgings, circular pieces, wire and tubing.

GH4145 Nickel alloy similar material are: W.Nr.2.4669

GH4145 Application field are:
The alloy has a high temperature environment good corrosion resistance and creep rupture strength, good mechanical properties, is widely used, below 980 ℃ have sufficient strength and corrosion resistance to oxidation

Producing a high temperature working spring, a bolt; gas turbine rotor blades on the impeller and other structural members;
On the rocket engine thrust chamber;
Thrust reverser on the plane;
Large pressure vessel;
Elastic gas were mounted, flexible seal die, rubber machinery electric blade.

GH4145 Superalloy alloy chemical composition:

Alloy

%

Ni

Cr

Fe

Nb

Co

C

Mn

Si

S

Cu

Al

Ti

GH4145

Min



14

5.0

0.7













0.4

2.25

Max

70

17

9.0

1.2

1.00

0.08

1.00

0.50

0.01

0.5

1.0

2.75

GH4145 alloy Mechanical Property:

Grade

Yield strength
Rm N/mm2

tensile strength
RP0.2N/mm2

Elongation
A5 %

HB

GH4145

1267

868

25

≤400

GH4145 alloy melting point : 1325-1370 ℃
GH4145 Nickel density : 8.90 g/cm3

GH4145 alloy has the following characteristics:
GH4145 below 980 ℃ has good resistance to corrosion and oxidation resistance below 800 ℃ with high strength, below 540 ℃ has good resistance to relaxation properties, but also has good formability and weldability, in the low-temperature environment has excellent mechanical

GH4145 Product form and Specifications:

AlloySheet/Plate/Strip/Coil

Seamless alloy tube/Pipe

Welded alloy tube/pipe

Ring/Bar/Rod

Forged product

Fittings/Flange

GB/T14992-2005.

China Special Steel Limited is a GH4145 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about GH4145 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
