Haynes 25 Nickel base alloy steel

Haynes 25 has an excellent temperature strength and oxidation resistance to 2000ºF. Haynes 25 is hot formable between 1900ºF- 2300ºF. Also known as Alloy L605, it is better to cold-work Haynes 25 for bending, spinning and drawing the components.

Haynes 25 Nickel alloy similar material is:UNS R30605

Haynes 25 usually used in the following industries :
Gas turbine engine combustion chambers and afterburners
High temperature ball bearings and bearing races
Springs
Heart valves

Haynes 25 Nickel base alloy Chemical Analysis:

	Ni	Cr	Mn	Si	Fe	S	Co
Max	11.00	21.00	2.00	0.40	3.00	0.030	Bal
Min	9.00	19.00	1.00

Haynes 25 Nickel base alloy Mechanical Property Requirements:

	Ultimate Tensile	Yield Strength (0.2% OS)	Elongation.in 4D %
Min	125 Ksi	45.0 KSi	30
Max	-	-	-
Min	862 Mpa	310 MPa
Max	-	-	-

Haynes 25 Features :
Outstanding high temperature strength
Oxidation resistant to 1800°F
Galling resistant
Resistant to marine environments, acids and body fluids
Hardenability

Hardness is typically 250 BHN and never higher than 275 BHN by specification. Not significantly hardenable. Does not respond to customary aging treatments, but strain aging at relatively low temperatures (700-1100°F) can improve creep and rupture strength when the alloy is in service at temperatures under 1300°F. Also, tensile and creep strength can be improved by cold working. It is an austenitic alloy.

Corrosion Resistance
Resistance to high temperature oxidation and carburization is good. The alloy, while not primarily intended for aqueous corrosion, is also resistant to corrosion by acids such as hydroelectric and nitric acid, as well as being resistant to wet chlorine solutions.

Density: 0.330 lbs./cubic inch

Haynes 25 Product form and Specifications:

Form	Standard
Bar	AMS 5759 ASTM F90 GE B50T26A
Cold Worked Bars	MCI 1031 GPS 2051
Sheet/Plate/coil	AMS 5537
Welding Tube	GE B50T26A
Forging	AMS 5759
Weld Wire	AMS 5759

China Special Steel Limited is a Haynes 25 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about Haynes 25 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
