High temperature high strength alloy steel X 8 NiCrAlTi 32-21
X 8 NiCrAlTi 32-21 is a fully austenitic low-carbon nickel - iron - chromium alloy in the same series of With X 8 NiCrAlTi 32-21, the cobalt content of alloy can be strictly controlled under 0.01%. X 8 NiCrAlTi 32-21 ability a lot of corrosion medium corrosion. Its high content of nickel in the aqueous corrosion condition has the very good resistance to stress corrosion cracking performance. X 8 NiCrAlTi 32-21 alloy steel usually applied in nitric acid condenser, nitric acid corrosion resistance, steam heating pipe and so one which request 500 degree working environment. X 8 NiCrAlTi 32-21 alloy steel usually be delivered with annealed state.
1. X 8 NiCrAlTi 32-21 equal material:W.Nr.1.4876, X10NiCrAlTi3220, NA15, UNS N08811, FeNi32Cr21AlTi, Z8NC32.21, Incoloy 800, W.Nr.1.4959. HT
% | Ni | Cr | Fe | Mo | Co | C | Mn | Si | S | P | Cu | Al | Ti |
min | 30.0 | 19.0 | 0.06 | 0.15 | 0.15 | ||||||||
max | 35.0 | 23.0 | 39.5 | 0.1 | 1.5 | 1.0 | 0.015 | 0.75 | 0.60 | 0.60 |
3. X 8 NiCrAlTi 32-21 Physical properties:
X 8 NiCrAlTi 32-21 alloy steel Density: 8.0g/cm3
X 8 NiCrAlTi 32-21 alloy steel Melting temperature range: 1350-1400 degree
4. X 8 NiCrAlTi 32-21 Mechanical properties at room temperature (minimum)
X 8 NiCrAlTi 32-21alloy steel product | specifications | yield strength RP0.2 N/mm2 | yield strength RP1.0 N/mm2 | Tensile strength Rm N/mm2 | elongation A50% | hardness HB |
cold rolling strip hot rolled plate | 0.5-6.4 | 240 | 265 | 585 | 30 | <=200 |
5-100 | 135-165 | |||||
bar Cold working Hot working | 1.6-64 | |||||
25-100 | ||||||
>100-240 | 220 | 250 | 550 | 35 | ||
pipe Cold working Hot working | 64-240 | 180 | - | 530 | 30 | - |
5-100 | 240 | 265 | 585 | 30 | ||
Condensation and heat exchanger | 16-76 |
5. Application: X 8 NiCrAlTi 32-21 alloy steel are widely used in various industrial sectors whose working temperature does not exceed 550 degree.
Typical applications are:
sulfuric acid pickling factories with the heating pipe, containers, baskets, and chain, etc.
water cooling heat exchanger, Marine products pipeline system, acidic gas pipeline environment. heat exchanger in phosphoric acid production, evaporator, washing, dip tube, etc.
