welcome to China Special Steel limited !
Home > Nickel alloys & super alloys > - JIS G4902/NCF 800
JIS G4902/NCF 800

JIS G4902/NCF 800

Product : JIS G4902/NCF 800

JIS G4902/NCF 800 Nickel base alloy due to its Ni, Cr content is high, so oxidation at high temperatures and high resistance to carburization, oxidation resistance superior to SUS 310S, even close to NAS 600. High temperature strength and NAS 600 is basically the same. During use will not lead to precipitation of σ phase and embrittlement, is widely used in heat-resistant material.

Generally in the temperature range below 600 ℃. If used at higher temperatures, and creep performance requirements, it is recommended to use NAS 800H/NAS 800T.

JIS G4902/NCF 800 Nickel base alloy Chemical composition :



C

Si

Mn

P

S

Ni

Cr

Cu

Al

Ti

Fe

Min

30.00

19.00

0.15

0.15

Max

0.10

1.00

1.50

0.030

0.015

35.00

23.00

0.75

0.60

0.60

Bal.

Mechanical properties at room temperature

JIS G4902/NCF 800 Nickel base alloy Mechanical properties

0.2% Yield Strength
(N/mm2)

Tensile strength
(N/mm2)

Elongation
(%)

Hardness

(HV)

(HB)

≧ 205

≧ 520

≧ 30

≦ 182

≦ 179

JIS G4902/NCF 800 Nickel base alloy Physical Properties

Specific heat (J/kg・K)

460

Resistivity (μΩ・cm)

99

Thermal conductivity (W/m・K)

12.6

Average Coefficient of thermal expansion(10-6/℃)

25–200℃

15.9

25–400℃

16.8

25–600℃

17.3

25–800℃

18.1

Longitudinal elastic modulus (MPa)

19.7 x 104

Curie point (℃)

-115

Ferromagnetic

No

Melting point (℃)

1357-1385


If necessary, please leave your message, we will contact you as soon as possible, thank you!

Name:
Email:
Tel:
Message:

Product
About Us
Manufacture
Recommended Product
