Monel 405 corrosion resistant alloy steel

Monel 405 corrosion resistant alloy steel

Monel 405 equal material : UNS N04405 Monel 405 alloy mechanical properties and corrosion resistance and Alloy 400 basic same, but has better cutting process ability. Suitable for batch manufacture of various types of threaded fasteners,valve parts, etc.

Monel 405 alloy Chemical composition:

alloy	Ni min	Fe	C max	Si max	Mn max	Cu	Others
Monel 405	63.0	2.5	0.30	0.5	2.0	28.0-34.0	0.024

Monel 405 alloy Physical properties:
Monel 405 alloy density: 8.80 mg/m3

Monel 405 alloy Melting point range: 1300~1350 degree

Monel 405 alloy Mechanical properties min value (room temperature)

Tensile strength	Yield strength	Elongation	State
550 Mpa	240 Mpa	40	Annealing state

Monel 405 Product features:
Monel 405 is a water, chemical solvents, ammonia, chlorine, hydrogen chloride, sulfur acid medium such as sulfuric acid,hydrofluoric acid, hydrochloric acid, phosphoric acid, organic acid, in alkaline medium, salt, and molten salt has good corrosion resistance of nickel base alloy material.

Monel 405 alloy application :
Monel 405 is used in chemical and petrochemical industry and Marine development, etc. Can be used to manufacture all kinds of heat exchange equipment, boiler feed water heater, oil and chemical pipelines, containers, towers, tank, valves, pumps, reaction kettle, shaft, etc
