Monel400 alloy is an amount of the largest and most versatile, excellent overall performance of corrosion resistant alloys. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas medium, hot concentrated alkali is also excellent in corrosion resistance. Also resistant to neutral solution, water, sea water, air, organic compounds corrosion. An important feature of the alloy is generally not produce stress corrosion cracking, good cutting performance.
Monel400 alloy Chemical composition
C |
Si |
Mn |
Ni |
Cu |
S |
Fe |
≤0.3 |
≤0.50 |
≤2.0 |
≥63 |
28~34 |
≤ 0.024 |
≤ 2.5 |
Monel400 alloy mechanical properties in various states
Materials and state |
Tensile strength /Mpa |
Yield Strength /Mpa |
Elongation % |
Hardness |
|
HB |
HRB |
||||
Rod material: annealed condition |
516~620 |
170~345 |
60~35 |
110~149 |
60~80 |
Thermal processing state(≤54mm Profiles) |
551~757 |
275~690 |
60~30 |
140~241 |
75~100 |
Thermal processing state(≥ 54mm Profiles) |
516~689 |
205~380 |
50~30 |
130~184 |
72~90 |
Cold-drawn state, stress relief treatment |
578~827 |
380~690 |
40~22 |
160~225 |
85~20HRC |
Plate: hot rolled |
516~655 |
380~390 |
45~30 |
125~215 |
70~96 |
Hot-rolled and annealed |
482~585 |
195~345 |
50~35 |
110~140 |
60~76 |
Thin plate: annealed |
482~585 |
170~310 |
50~35 |
|
|
Cold-rolled, Hard |
689~964 |
620~755 |
15~2 |
|
|
Cold-rolled strip: annealed |
517~585 |
170~310 |
50~35 |
|
|
Tempered |
689~964 |
620~895 |
15~2 |
|
|
Supporting consumables
Monel Monel400 electrode (ENiCu-7), Monel400 wire (ERNiCu-70)
Monel400 alloy Application
Marine heat exchangers, desalination equipment, salt production equipment, marine and chemical processing equipment, propeller shafts and pumps, gasoline and water tanks
