NiMo16Cr15W is a nickel-molybdenum-chromium wrought alloy that is generally used as corrosion-resistance. NiMo16Cr15W is among the more well known Hastelloy grades for general corrosion service.
NiMo16Cr15W alloy steel Chemical composition :
C |
Mn |
Si |
S |
P |
Cr |
Mo |
W |
Fe |
Co |
V |
0.010 |
1.00 |
0.08 |
0.010 |
0.025 |
14.50-16.50 |
15.00-17.00 |
3.00-4.50 |
4.00-7.00 |
2.5 |
0.35 |
Corrosion-resistant alloy. Time-temperature-sensitization (TTS) diagram for Nicrofer 5716 hMoW and Nicrofer 5923 hMo according to the Streicher test (ASTM G-28, Method A).
Source: Not shown in this demonstration version.
NiMo16Cr15W Mechanical properties
Product Form |
Tensile(ksi) |
2% Yield (ksi) |
Elongation% |
Bar |
110.0 |
52.6 |
62 |
Plate |
107.0 |
50.3 |
67 |
Sheet |
4115.5 |
54.6 |
60 |
Tube & Pipe |
105.4 |
45.4 |
70 |
NiMo16Cr15W alloy Specifications :
1.bar wire dia:5.5~1000mm;
2.pipe tube outdia:6~3500mm;
3.plate coil wideth:10~2000mm;
4.strip coil thickness:0.3~16mm
NiMo16Cr15W alloy is able to endure the corrosion of oxidation resistance chloride water solution and damp cholrinum and pypocholoride.and it can be used for Making the welding structure members which working in the environment of strong corrosivity of complex medium of oxidation-reduction and high temperature seawater.
