Nickel 200 is solid solution strengthened, commercially pure wrought materials with good mechanical properties over a wide range of temperatures and excellent resistance to many corrosives, in particular hydroxides. Nickel 201 was a modification of 200 to control carbon (.02 max) which keeps it from being embrittled by intergranular precipitates at temperatures of 600°F to 1400°F in many processes. Typically, the elemental restrictions of both, nickel 200 and nickel 201, are combined into one, dual-certified chemistry resulting in a single alloy with the desired characteristics of both alloys, Nickel 200/201.
Nickel 200 alloy steel similar material are:UNS N02200,W.Nr. 2.4060,W.Nr. 2.4066
Nickel 200 Application fields :
Food processing equipment, salt refining equipment.
Mining and ocean mining.
At above 300 degree under the condition of equipment needed for manufacturing industrial sodium hydroxide.
mining and ocean mining.
At above 300 degree under the condition of equipment needed for manufacturing industrial sodium hydroxide.
Nickel 200 alloy steel Chemical composition:
Ni |
Fe |
Cu |
C |
Mn |
S |
Si |
99.0 min |
0.40 max |
0.25 max |
0.15 max |
0.35 max |
0.01 max |
0.35 max |
Nickel 200 alloy Physical properties:
Nickel 200 Density: 8.89 g/cm3
Nickel 200 Melting point: 1440 degree
Nickel 200 alloy steel the mechanical properties at room temperature, the minimum value
Product form |
Condition |
Tensile (ksi) |
.2% Yield (ksi) |
Elongation (%) |
Hardness (HRB) |
Rod & Bar |
Hot Finished |
60-85 |
15-45 |
55-35 |
45-80 |
Rod & Bar |
ColdDrawn/Annealed or Hot-Finished/Annealed |
55-75 |
15-30 |
55-40 |
45-70 |
Plate |
Hot-Rolled/Annealed |
55-80 |
15-40 |
60-40 |
45-75 |
Sheet |
Annealed |
55-75 |
15-30 |
55-40 |
70 max |
Tube & Pipe |
Seamless Annealed |
55-75 |
12-30 |
60-40 |
70 max |
Nickel 200 characteristics:
Highly resistant to various reducing chemicals
Excellent resistance to caustic alkalies
High electrical conductivity
Excellent corrosion resistance to distilled and natural waters
Resistance to neutral and alkaline salt solutions
Excellent resistance to dry fluorine
Widely used to handle caustic soda
Good thermal, electrical and magnetostrictive properties
Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations
Nickel 200 Product form and Specifications:
Product |
ASTM |
Alloy Sheet/Plate/Strip/Coil |
B162 |
Seamless alloy tube/Pipe |
B161 |
Welded alloy tube/pipe |
B622 |
Ring/Bar/Rod |
B160 |
Forged product |
B564 |
Fittings/Flange |
B163 |
China Special Steel Limited is a Nickel 200 alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about Nickel 200 alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
