UNS N06445 is a nickel-chromium-molybdenum alloy which has improved thermal stability. In this alloy, the tungsten was totally omitted and the iron content was reduced to approximately 1%.
Outstanding high-temperature stability exhibits good ductility and corrosion resistance after long-time aging at 650 to 1040 degree C . Resists formation of grain-boundary precipitates in weld heat-affected zones, and is suitable for most chemical process applications in the as-welded condition. Has excellent resistance to stress-corrosion cracking and to oxidizing atmospheres up to 1040 degree C
UNS N06445 has exceptional resistance to a variety of chemical process environments, including hot contaminated mineral acids, solvents, chlorine, and chlorine-contaminated media (organic and inorganic, dry chlorine, formic and acetic acids, acetic anhydride, seawater, and brine).
UNS N06445 Nickel alloy similar material is : Hastelloy C4,W.NR.2.4610
UNS N06445 Nickel alloy application :
UNS N06445 alloy is widely used in the field of energy production and pollution control, chemical, petrochemical, especially in the sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid industry
UNS N06445 chemical composition:
|
|
Ni |
Cr |
Mo |
Fe |
Ti |
Co |
C |
Mn |
Si |
P |
S |
|
Min |
Balance |
14.5 |
14 |
|
|
|
|
|
|
|
|
|
Max |
17.5 |
17 |
3.0 |
0.7 |
2.0 |
0.009 |
1.0 |
0.05 |
0.025 |
0.010 |
UNS N06445 Mechanical Property:
|
Grade |
Density |
Melting point |
|
UNS N06445 |
8.6g/cm3 |
1335°C-1380°C |
UNS N06445 Mechanical Property:
|
Alloy state |
Tensile strength MPa |
Yield strength MPa |
elongation A5 % |
|
UNS N06445 alloy bar |
690 |
275 |
40 |
|
UNS N06445 alloy Hot rolled plate |
690 |
275 |
40 |
|
UNS N06445 alloy colled rolled sheet |
690 |
275 |
40 |
|
UNS N06445 alloy strip |
690 |
275 |
40 |
UNS N06445 Product form and Specifications
|
Product |
ASTM |
ASME |
|
Alloy Sheet/Plate/Strip/Coil |
B575 |
SB575 |
|
Seamless alloy tube/Pipe |
B622 |
SB622 |
|
Welded alloy tube/pipe |
B619/B622 |
SB619/SB622 |
|
Ring/Bar/Rod |
B574 |
SB574 |
|
Forged product |
B564 |
SB564 |
|
Fittings/Flange |
B336 |
SB336 |
China Special Steel Limited is a UNS N06445 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about UNS N06445 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
