Product : UNS N08800(NAS 800L)
NAS 800L Nickel base alloy is in chloride environments with excellent corrosion resistance of the alloy. NAS 800H has good high corrosion resistance, also for acid-resistant steel. NAS 800T i maintained at a good high temperature strength, corrosion resistance and oxidation resistance of high heat-resistant nickel steel, characterized by maintaining a high degree of microstructural stability at high temperatures. Is by high temperature heat treatment of the grain size and the C (carbon), Ti (titanium), control Al (aluminum) content of the obtained high creep strength.
NAS 800 (NCF 800, UNS N08800) - comparable with Incoloy® 800 alloy - is a high-nickel heat-resistant steel, high temperature environments with good strength and corrosion resistance, oxidation resistance. Component tissue close to the austenitic stainless steel, Inconel® alloy and having equivalent characteristics.
NAS 800L Nickel base alloy Chemical composition(wt%)
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Al |
Ti |
Cu |
≤0.10 |
≤1.0 |
≤1.50 |
≤0.030 |
≤0.015 |
30.0~ 35.0 |
19.00~ 23.00 |
0.15~ 0.60 |
0.15~ 0.60 |
≤0.75 |
0.012 |
0.30 |
0.27 |
0.015 |
0.0005 |
30.5 |
19.9 |
0.32 |
0.40 |
0.03 |
Corresponding specifications
JIS G4902 : NCF 80
ASTM A240 : UNS N08800,ASTM B409 : UNS N08
ASME SB-409 : UNS N08800
NAS 800L Nickel base alloy Physical Characteristics
Density (g/cm3) |
|
8.02 |
Specific heat (J/g.K) |
|
0.460 |
Thermal conductivity (W/cm.K) |
|
0.17 |
Fixed resistor (μΩ.cm) |
|
99 |
Coefficient of thermal expansion (×10-6/K) |
38~100℃ |
14.2 |
|
38~400℃ |
16.6 |
|
38~850℃ |
18.4 |
NAS 800L Nickel base alloy Mechanical properties
0.2% Y.S(N/mm2) |
T.S(N/mm2) |
El(%) |
HV |
228 |
556 |
42 |
126 |
Weldability
NAS 800 austenitic stainless steel welding and the same standard, can be TIG welding, MIG welding and manual arc welding.
NAS 800L Nickel base alloy application
Widely used in a mantle heater jacket tube, thermocouple protection tubes, heat treatment furnace, as well as materials for use in high temperature environments.
