UNS R30006 Alloy steel

UNS R30006 is a kindly of Nickel base anti-corrosion alloy with many excellent performance, good for oxidation and reduction of medium corrosion resistance ability. There are only several material has damp resistance Chlorine, hypochlorite and chlorine dioxide solution corrosion, UNS R30006 alloy is one of them.

UNS R30006 Nickel alloy similar material are :Cobalt alloy 6B

UNS R30006 Nickel alloy usually used in the following industries :
UNS R30006 wrought base-cobalt alloys No. 6B and 6K have been used successfully for many years in applications involving severe conditions of wear or wear combined with corrosion and/or high temperature. They are used particularly for shaft sleeves, bushings, valve parts, pump plungers, doctor blades, feed screws, knives, wear plates, and bearings.

UNS R30006 Nickel base alloy chemical composition :

Alloy	Cobalt	Nil	Si	Fe	Ma	Cr	Mo	Ti	C
No. 6B	Bal	3.00 max	2.00 max	3.00 max	2.00 max	28.00- 32.00	1.50 max	3.50- 5.50	0.90- 1.40
No. 6K	Bal	3.00 max	2.00 max	3.00 max	2.00 max	28.00 32.00	1.50 max	3.50- 5.50	1.40- 1.90

UNS R30006 Nickel base alloy Mechanical Property:

Form	Condition(Solution )	Ultimate Tensile Strength Ksi (MPa)	Yield Strength at 0.2% offset, Ksi (MPa)	Elongation in 2 in., (50.8mm), %	Hardness Rockwell C
Sheet 0.040 in. (1.0 mm),thick	Heat-treated*	145.0(1000)a	90.1(621)a	12a	36a
Sheet 0.065 in. (1.7 mm),thick	Heat-treated*	140.8(971)a	86.7(598)a	11a	36a
Sheet 0.125 in. (3.2 mm),thick	Heat-treated*	144.7(998)a	89.8(619)a	11a	37a
Sheet 0.187 in. (4.8 mm),thick	Heat-treated*	144.5(996)a	89.3(616)a	10a	37a
Plate 0.312 in. (7.9 mm),thick	Heat-treated* Aged 3 hrs at 1500°F (816°C)	140.2(967)b 142.4(982)	87.9(606)b 97.7(674)	10b 4c	Plate 0.312 in. (7.9 mm),thick
Plate 0.437 in. (11.1 mm),thick	Heat-treated* Aged 3 hrs at 1500°F (816°C)	140.2(967)a 146.7(1012)c	85.6(590)a 96.3(664)c	12a 5c	Plate 0.437 in. (11.1 mm),thick

Corrosion Resistance
In addition to its wear-resistance, UNS R30006 has good resistance to a variety of corrosive media. This combination of properties makes alloy No. 6B particularly useful in such applications as food handling machinery, chemical equipment, and others where both wear - and corrosion-resistance are necessary.

Where extraordinary resistance to corrosion is required, one of the Hastelloy nickel-based alloys may prove more suitable.

Heat Treatment
Wrought forms of alloy No. 6B and No. 6K are supplied in the solution heat-treated condition unless otherwise specified. The standard heat-treatment is at 2250°F (1232°C) followed by air cooling.

UNS R30006 Product form and Specifications:

Product	AMS
Alloy Sheet/Plate/Strip/Coil	AMS5894

China Special Steel Limited is a UNS R30006 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about UNS R30006 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
