UNS R30605 has an excellent temperature strength and oxidation resistance to 2000ºF. UNS R30605 is hot formable between 1900ºF- 2300ºF. Also known as Alloy L605, it is better to cold-work UNS R30605 for bending, spinning and drawing the components.
UNS R30605 Nickel alloy similar material is:Haynes 25
UNS R30605 usually used in the following industries :
Gas turbine engine combustion chambers and afterburners
High temperature ball bearings and bearing races
Springs
Heart valves
UNS R30605 Nickel base alloy Chemical Analysis:
|
Ni |
Cr |
Mn |
Si |
Fe |
S |
Co |
Max |
11.00 |
21.00 |
2.00 |
0.40 |
3.00 |
0.030 |
Bal |
Min |
9.00 |
19.00 |
1.00 |
|
|
|
|
UNS R30605 Nickel base alloy Mechanical Property Requirements:
|
Ultimate Tensile |
Yield Strength (0.2% OS) |
Elongation.in 4D % |
Min |
125 Ksi |
45.0 KSi |
30 |
Max |
- |
- |
- |
Min |
862 Mpa |
310 MPa |
|
Max |
- |
- |
- |
UNS R30605 Features :
Outstanding high temperature strength
Oxidation resistant to 1800°F
Galling resistant
Resistant to marine environments, acids and body fluids
Hardenability
Hardness is typically 250 BHN and never higher than 275 BHN by specification. Not significantly hardenable. Does not respond to customary aging treatments, but strain aging at relatively low temperatures (700-1100°F) can improve creep and rupture strength when the alloy is in service at temperatures under 1300°F. Also, tensile and creep strength can be improved by cold working. It is an austenitic alloy.
Corrosion Resistance
Resistance to high temperature oxidation and carburization is good. The alloy, while not primarily intended for aqueous corrosion, is also resistant to corrosion by acids such as hydroelectric and nitric acid, as well as being resistant to wet chlorine solutions.
Density: 0.330 lbs./cubic inch
UNS R30605 Product form and Specifications:
Form |
Standard |
Bar |
AMS 5759 ASTM F90 GE B50T26A |
Cold Worked Bars |
MCI 1031 GPS 2051 |
Sheet/Plate/coil |
AMS 5537 |
Welding Tube |
GE B50T26A |
Forging |
AMS 5759 |
Weld Wire |
AMS 5759 |
China Special Steel Limited is a UNS R30605 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about UNS R30605 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
