W.NR.2.4610 Nickel alloy steel

W.NR.2.4610 is a nickel-chromium-molybdenum alloy which has improved thermal stability. In this alloy, the tungsten was totally omitted and the iron content was reduced to approximately 1%.

Outstanding high-temperature stability exhibits good ductility and corrosion resistance after long-time aging at 650 to 1040 degree C . Resists formation of grain-boundary precipitates in weld heat-affected zones, and is suitable for most chemical process applications in the as-welded condition. Has excellent resistance to stress-corrosion cracking and to oxidizing atmospheres up to 1040 degree C

W.NR.2.4610 has exceptional resistance to a variety of chemical process environments, including hot contaminated mineral acids, solvents, chlorine, and chlorine-contaminated media (organic and inorganic, dry chlorine, formic and acetic acids, acetic anhydride, seawater, and brine).

W.NR.2.4610 Nickel alloy similar material is : UNS N06445Hastelloy C4

W.NR.2.4610 Nickel alloy application :
W.NR.2.4610 alloy is widely used in the field of energy production and pollution control, chemical, petrochemical, especially in the sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid industry

W.NR.2.4610 chemical composition:

	Ni	Cr	Mo	Fe	Ti	Co	C	Mn	Si	P	S
Min	Balance	14.5	14
Max	Balance	17.5	17	3.0	0.7	2.0	0.009	1.0	0.05	0.025	0.010

W.NR.2.4610 Mechanical Property:

Grade	Density	Melting point
W.NR.2.4610	8.6g/cm3	1335°C-1380°C

W.NR.2.4610 Mechanical Property :

Alloy state	Tensile strength MPa	Yield strength MPa	elongation A5 %
W.NR.2.4610 alloy bar	690	275	40
W.NR.2.4610 alloy Hot rolled plate	690	275	40
W.NR.2.4610 alloy colled rolled sheet	690	275	40
W.NR.2.4610 alloy strip	690	275	40

W.NR.2.4610 Product form and Specifications:

Product	ASTM	ASME
Alloy Sheet/Plate/Strip/Coil	B575	SB575
Seamless alloy tube/Pipe	B622	SB622
Welded alloy tube/pipe	B619/B622	SB619/SB622
Ring/Bar/Rod	B574	SB574
Forged product	B564	SB564
Fittings/Flange	B336	SB336

China Special Steel Limited is a W.NR.2.4610 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about W.NR.2.4610 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
