W.Nr.2.4660 is a nickel-iron-chromium austenitic alloy that was developed for maximum resistance to acid attack, specifically sulfuric acid. This superalloy has excellent resistance to general corrosion, pitting, and crevice corrosion in chemicals containing chlorides and sulfuric, phosphoric, and nitric acids. It also contains niobium for stabilization against sensitization and resultant intergranular corrosion. W.Nr.2.4660 combines excellent corrosion resistance with elevated mechanical properties and relatively easy fabrication. Although originally designed for use in sulfuric acid related industries.
W.Nr.2.4660 Nickel steel similar material are:UNS N08020,Alloy 20,NiCr20CuMo
W.Nr.2.4660 usually used in the following industries :
Synthetic rubber manufacturing equipment
Processing of pharmaceuticals, plastics and organic and heavy chemicals
Tanks, piping, heat exchangers, pumps, valves, and other process equipment
Acid cleaning and pickling equipment
Chemical process piping, reactor vessels
Bubble caps
Petrochemical process equipment
Food and dye production
W.Nr.2.4660 Nickel steel chemical composition :
Ni |
Fe |
Cr |
Cu |
Mo |
Nb |
C |
Mn |
P |
S |
Si |
32.00-38.00 |
Balance |
19.0-21.0 |
3.0-4.0 |
2.0-3.0 |
8xC-1.0max |
0.07max |
2.0max |
0.045max |
0.035max |
1.0max |
W.Nr.2.4660 Nickel steel Mechanical Properties(Annealed Materia)
Form |
Tensile Min. |
Yield Min. (.2% offset) |
Elongation Min. |
Reduction of Area Min. |
Bar (hot or cold finished) |
80 ksi |
35 ksi |
30% |
50% |
Sheet/Plate |
80 ksi |
35 ksi |
30% |
- |
W.Nr.2.4660 Nickel steel characteristics:
Excellent general corrosion resistance to sulfuric acid
Excellent resistance to chloride stress corrosion cracking
Excellent mechanical properties and fabricability
Minimal carbide precipitation during welding
Excels in resisting corrosion to hot sulfuric acids
W.Nr.2.4660 Product form and Specifications:
Product |
ASTM |
Pipe Seamless |
B729 |
Pipe Welded |
B464 |
Tube Seamless |
B729 |
Tube Welded |
B468 |
Sheet/Plate |
B463 |
Ring/Bar/Rod |
B473 |
Forging |
B462 |
Fitting |
B366 |
China Special Steel Limited is a W.Nr.2.4660 Nickel steel Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about W.Nr.2.4660 Nickel steel chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
