X10NiCrAlTi3220 is a nickel-iron-chromium alloy with good strength and excellent resistance to oxidation and carburization in high-temperature exposure. X10NiCrAlTi3220 nickel steel alloy is identical. X10NiCrAlTi3220 was the first of these alloys and it was slightly modified into X10NiCrAlTi3220H. This modification was to control carbon (.05-.10%) and grain size to optimize stress rupture properties. The nickel content makes the alloys highly resistant to both chloride stress-corrosion cracking and to embrittlement from precipitation of sigma phase. The general corrosion resistance is excellent.
X10NiCrAlTi3220 Nickel alloy similar material are:UNS N08800,W.Nr.1.4876,Incoloy 800
X10NiCrAlTi3220 Nickel alloy usually used in the following industries :
Ethylene furnace quench boilers
Hydrocarbon cracking
Valves, fittings and other components exposed to corrosive attack from 1100-1800° F
Industrial furnaces
Heat-treating equipment
Chemical and petrochemical processing
Super-heater and re-heaters in power plants
Pressure vessels
Heat exchangers
X10NiCrAlTi3220 Alloy steel Chemical Composition, %
|
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
0.75 max |
0.15-0.60 |
0.15-0.60 |
0.1 max |
1.5 max |
0.015 max |
1.0 max |
X10NiCrAlTi3220 Alloy steel Mechanical Property:
|
Product |
Tensile (ksi) |
2% Yield (ksi) |
Elongation (%) |
|
Rod & Bar |
75-100 |
30-60 |
60-30 |
X10NiCrAlTi3220 alloy density : 8.0g/cm3
Melting: 1350-1400 degree
X10NiCrAlTi3220 Product form and Specifications:
|
Product |
ASTM |
|
Pipe Seamless |
B407 |
|
Pipe Welded |
B154 |
|
Tube Seamless |
B163 |
|
Tube Welded |
B515 |
|
Sheet/Plate |
B409 |
|
Ring/Bar/Rod |
B408 |
|
Forging |
B564 |
|
Fitting |
B366 |
China Special Steel Limited is a X10NiCrAlTi3220 Nickel alloy Sheet/Plate/Strip/Coil/tube/Pipe/ Ring/Bar/Rod/Forging/Fittings/Flange professional manufacturer and supplier. If you have any information about X10NiCrAlTi3220 Nickel alloy chemical composition, Mechanical property, density,Heat treatment, melting point ,or any other service, please contact with our sales team.
