ABS A36 L shape steel bars

ABS Grade A36 shape steel bar with good toughness properties, higher strength. ABS Grade A36 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality ABS Grade A36 L shape steel bar shipbuilding steel. China special steel limited has a large number of stocks.

ABS Grade A36 L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

ABS AH36, AB/AH36 chemical composition in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
AH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness > 50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

ABS AH36, AB/AH36 Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		> 50-70		> 70-100
					L	C	L	C	L	C
AB/AH36	490-630	355	21	0	34	24	41	27	50	34

ABS AH36, AB/AH36 shipbuilding angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	> 12.5-20	> 20-25	> 25-35	> 35-50	> 50-100
AH36	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
		Profile steel			N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
			A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find ABS Grade A36 L shape steel bar, ABS A36 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar supplier, ABS Grade A36 L shape steel bar, ABS A36 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, ABS Grade A36 L shape steel bar, ABS A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited give you ABS Grade A36 L shape steel bar, ABS A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, ABS Grade A36 L shape steel bar,ABS A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
