ABS D32 L shape steel bars

ABS Grade D32 shape steel bar with good toughness properties, higher strength. ABS Grade D32 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality ABS Grade D32 L shape steel bar shipbuilding steel bars China special steel limited has a large number of stocks.

ABS Grade D32 L shape steel bar specifications:
200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

ABS DH32, AB/DH32 chemical composition in shipbuilding steel angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max
AB/DH32	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness > 50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
ABS DH32, AB/DH32 Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		> 50-70		> 70-100
					L	C	L	C	L	C
AB/DH32	440-570	315	22	-20	31	22	38	26	46	31

ABS DH32, AB/DH32 shipbuilding angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	> 12.5-20	> 20-25	> 25-35	> 35-50	> 50-100
DH32	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find ABS Grade D32 L shape steel bar, ABS D32 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar supplier, ABS Grade D32 L shape steel bar, ABS D32 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, ABS Grade D32 L shape steel bar, ABS D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited give you ABS Grade A32 L shape steel bar, ABS D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, ABS Grade D32 L shape steel bar,ABS D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
