GL Grade A32 L shape steel bars

GL Grade A32 shape steel bar with good toughness properties, higher strength. GL Grade A32 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality GL Grade A32 L shape steel bar shipbuilding steel bars. China special steel limited has a large number of stocks.

GL Grade A32 L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

GL A, GL A32 chemical composition in shipbuilding steel, angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max
GL-A32	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

GL AH32, GL-A32 Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
GL-A32	440-570	315	22	0	31	22	38	26	46	31

GL AH32, GL-A32 Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar GL AH32, GL-A32 shipbuilding angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
GL-A32	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL Grade A32 L shape steel bar, GL A32 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL Grade A32 L shape steel bar, GL A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL Grade A32 L shape steel bar, GL A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited give you GL Grade A32 L shape steel bar, GL A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL Grade A32 L shape steel bar,GL A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
