GL Grade A36 L shape steel bars

GL Grade A36 shape steel bar with good toughness properties, higher strength. GL Grade A36 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality GL Grade A36 L shape steel bar shipbuilding steel bars. China special steel limited has a large number of stocks.

GL Grade A36 L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 ×9 × 14, 200 × 90 ×10 mes&ti;14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

GL A, GL A36 chemical composition in shipbuilding steel bars, angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
AH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be > 0.40%. If the delivery condition is TMPC, the CE will be : > 0.36% (thickness > 50mm),>0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
GL AH36, GL-A36 Mechanical Property in shipbuilding steel bars, angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					> 50		>50-70		>70-100
					L	C	L	C	L	C
GL-A36	490-630	355	21	0	34	24	41	27	50	34

GL AH36, GL-A36 shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			> 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
AH36	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
		Profile steel			N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
			A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL Grade A36 L shape steel bar, GL A36 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL Grade A36 L shape steel bar, GL A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL Grade A36 L shape steel bar, GL A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited give you GL Grade A36 L shape steel bar, GL A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL Grade A36 L shape steel bar,GL A36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
