NK Grade D36 L shape steel bars

NK Grade D36 L shape steel bar with good toughness properties, higher strength. NK Grade D36 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality NK Grade D36 L shape steel bar shipbuilding steel bars. China special steel limited has a large number of stocks.

NK Grade D36 L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

NK Grade D36 L shape steel bar, K A36 chemical composition:
NK DH36, K D36 NK DH36 Z15, NK DH36 Z25,NK DH36 Z35
chemical composition in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
DH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

NK DH36, K D36 NK DH36 Z15, NK DH36 Z25,NK DH36 Z35
Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
K D36	490-630	355	21	-20	34	24	41	27	50	34

NK DH36, K D36 NK DH36 Z15, NK DH36 Z25,NK DH36 Z35
shipbuilding angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
DH36	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find NK Grade D36 L shape steel bar, D36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar supplier, NK Grade D36 L shape steel bar, K D36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, NK Grade D36 L shape steel bar, K D36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited ’s sales team. We will give you the NK Grade D36 L shape steel bar, K D36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, NK Grade D36 L shape steel bar, K D36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
