RINA Grade D32 L shape steel bars

RINA Grade D32 L shape steel bar with good toughness properties, higher strength. RINA Grade D32 L shape steel bar are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality RINA Grade D32 L shape steel bar shipbuilding steel bars. China special steel limited has a large number of stocks.

RINA Grade D32 L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

RINA Grade D32, RINA Grade D32 chemical composition in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max
RI/D32	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

RINA DH32, RI/D32 Mechanical Property in shipbuilding angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
RI/D32	440-570	315	22	-20	31	22	38	26	46	31

RINA DH32, RI/D32 shipbuilding angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
DH32	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find RINA Grade D32 L shape steel bar, RINA D32 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar supplier, RINA Grade D32 L shape steel bar, RINA D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, RINA Grade D32 L shape steel bar, RINA D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited ’s sales team. We will give you the RINA Grade D32 L shape steel bar, RINA D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, RINA Grade D32 L shape steel bar, RINA D32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
