GL A32 angle steel bar

GL AH32 angle with good toughness properties,higher strength.GL AH32 angle are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality GL AH32 angle shipbuilding steel plate.China special steel limited has a large number of stocks.
We can supply :100× 75 × 7/10, 100×75×8/10, 125 × 75 × 7/10, 125×75×8/10, 150 × 90 × 9/12, 150×90×10/12, 150×100×12
GL A32 angle steel chemical composition:

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max
GL-A32	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
GL A32 angle steel mechanical property:

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
GL-A32	440-570	315	22	0	31	22	38	26	46	31

GL A32 angle steel delivery condition:

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
GL-A32	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

China special steel limited keeps more than 10,000 tons hot rolled and cold rolled GL AH32, GL-A32 angle shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL AH32, GL-A32 angle shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL AH32, GL-A32 angle shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL AH32, GL-A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited ’s sales team. We will give you the GL AH32, GL-A32 angle shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL AH32, GL-A32 angle shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
