GL D36 angle steel bar

GL D36 angel shipbuilding steel with good toughness properties,higher strength.GL D36 angle are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality GL D36 shipbuilding steel bars.China special steel limited has a large number of stocks.
We can supply :100× 75 × 7/10, 100×75×8/10, 125 × 75 × 7/10, 125×75×8/10, 150 × 90 × 9/12, 150×90×10/12, 150×100×12
GL D36 angle steel bars chemical composition:

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
D36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness > 50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
GL D36 angle steel bars mechanical property:

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		> 50-70		> 70-100
					L	C	L	C	L	C
GL-D36	490-630	355	21	-20	34	24	41	27	50	34

GL D36 angle steel bars delivery condition:

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	> 12.5-20	> 20-25	> 25-35	> 35-50	> 50-100
D36	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

China special steel limited keeps more than 10,000 tons hot rolled and cold rolled GL D36, GL-D36 angle shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL D36, GL-D36 angle shipbuilding steel bars/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL D36, GL-D36 angle shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL D36, GL-D36 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited s sales team. We will give you the GL D36, GL-D36 angle shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL D36, GL-D36 angle shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
