LR A36 angle steel bars

LR AH36 angle with good toughness properties,higher strength.LR AH36 angle are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality LR AH36 angle shipbuilding steel.China special steel limited has a large number of stocks.
We can supply:100× 75 × 7/10, 100×75×8/10, 125 × 75 × 7/10, 125×75×8/10, 150 × 90 × 9/12, 150×90×10/12, 150×100×12
LR Grade AH36 angle steel chemical composition:

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
AH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
LR AH36 angle steel bars mechanical property:

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
LR/AH36	490-630	355	21	0	34	24	41	27	50	34

LR AH36 angle steel bars delivery condition:

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
AH36	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
		Profile steel			N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
			A(50)	N(50),CR(50),TM(50),AR*(25)				-

China special steel limited keeps more than 10,000 tons hot rolled and cold rolled LR AH36, LR/AH36 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find LR AH36, LR/AH36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar supplier,LR AH36, LR/AH36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, LR AH36, LR/AH36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited’s sales team. We will give you the LR AH36, LR/AH36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, LR AH36, LR/AH36 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
