NK A32 angle steel bars

NK Grade A32 angle steel with good toughness properties, higher strength. NK Grade A32 angle steel are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans. All of our stock is the high quality NK Grade A32 angle steel shipbuilding steel bars. China special steel limited has a large number of stocks.
NK Grade A32 angle steel specifications: 100× 75 × 7/10, 100×75×8/10, 125 × 75 × 7/10, 125×75×8/10, 150 × 90 × 9/12, 150×90×10/12, 150×100×12
NK Grade A32 angle steel, K A32 chemical composition:

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max
K A32	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm),≤0.38%( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
NK AH32, K A32 Mechanical Property in shipbuilding steel bars, angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
K A32	440-570	315	22	0	31	22	38	26	46	31

NK AH32, K A32 shipbuilding steel, angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
K A32	Nb+V or V	Plate/sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled NK AH32, K A32 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find NK AH32, K A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar supplier,NK AH32, K A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, NK AH32, K A32 shipbuilding steel /sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact China special steel limited’s sales team. We will give you the NK AH32, K A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, NK AH32, K A32 shipbuilding steel/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
