B23R085 cold rolled coils

B23R085 B:China special steel limited, R: Series of magnetic domains oriented silicon steel sheet.23 : Thickness 0.23mm, 23/100 for the product thickness, in mm., 085/100 indicates that the product core loss not greater than 0.85w / kg.

B23r085 is a soft magnetic alloy ferrosilicon very low carbon content, usually silicon content of 0.5 to 4.5%. Added silicon can improve iron resistivity and maximum permeability and lower coercive force, core loss (iron loss) and magnetic aging.

B23R085 steel Mechanical Properties

Grade	tensile strength L（N/mm2）	Yield Strength L（N/mm2）	Elongation L（%）	Hardness HV1	Bending frequency (times)	Stacking factor（%）	tensile strength L（N/mm2）
B23P085	0.23	353	326	12	195	19	96.5

NOTE:. A detector according to GB / t228-2002, GB / T 19289-2003
b. above are typical values only for reference does not guarantee
c. L direction refers to the rolling direction

B23P085 electromagnetic performance standards

Grade	Nominal thickness（mm）	Theoretical density（kg/dm3）	Maximum core loss P17/50 (W/kg)	The minimum magnetic induction B8 （T）
B23P085	0.23	7.65	0.85	1.87

NOTE:. A detector according to GB / T 3655-2008 (G-series and P-series), GB / T3789-2008 (R Series)
b . G-series and P-series samples were rolling direction, and incubated for 2 hours at 800 ℃ magnetically eliminate stress after annealing treatment can be tested
c . P17/50 represents the maximum magnetic flux density of 1.7T, a frequency of 50Hz, the unit kg sample of core loss.

d . B50 represents the magnetic field intensity corresponding to the intensity of the magnetic induction 5000A / m when.

B23R085 steel Features:
1 . stable performance: advanced equipment, manufacturing technology and strict management to ensure the stability of the magnetic and mechanical properties.
2 . excellent processing performance: high dimensional accuracy and a smooth surface for easy cutting and punching, slitting steel for high-speed blanking.
3 . excellent coating properties:. BS series of electrical steel insulation coating has excellent insulating properties, adhesion, punching, heat resistance and weldability, with anti-corrosion (oil and chemicals) role.
4 . high dimensional accuracy: China special steel limited advanced equipment and manufacturing technology to ensure the BS series has excellent flatness, smooth surface, uniform thickness, with a small difference plate, lamination factor.

B23R085 steel application :
B23R085 steel mainly used in automotive, excavators, bulldozers, Various types of cranes etc.

China special steel limited Will return you with high-quality products and complete after-sale service with the lowest price. we committed to exceed customer's expectation on the basis of quality, price, and delivery. We sincerely hope to establish long-term cooperation relationship with you on the basis of mutual benefit, reciprocity and common development. As B23R085 Mechanical and B23R085 suppliers, we can supply B23R085 Chemical, B23R085 Mechanical and B23R085 standard for you.
