B50AH1000 cold rolled coils

B50AH1000 cold rolled coils

B50AH1000 is a soft magnetic alloy ferrosilicon very low carbon content, usually silicon content of 0.5 to 4.5%. Added silicon can improve iron resistivity and maximum permeability and lower coercive force, core loss (iron loss) and magnetic aging.

B50AH1000 steel surface is smooth, flat and uniform thickness can be improved fill factor core, adhesion and weldability surface of the insulating film is good, and can improve the corrosion resistance punching

B50AH1000 steel Mechanical Properties

Grade

Nominal thickness(mm)

tensile strength L(N/mm2)

Yield Strength L(N/mm2)

Elongation L(%)

Hardness HV1

Bending frequency (times)

Stacking factor(%)

B50AH1000

0.50

7.85

360

233

41

114

≥15

B50AH1000 steel sheet/plate Electromagnetic induction standard

Grade

Nominal thickness(mm)

Theoretical density(kg/dm3)

Maximum core loss P17/50
(W/kg)

minimum magnetic induction B8
(T)

B50AH1000

0.50

7.85

10.00

1.75

China special steel limited Will return you with high-quality products and complete after-sale service with the lowest price. we committed to exceed customer's expectation on the basis of quality, price, and delivery. We sincerely hope to establish long-term cooperation relationship with you on the basis of mutual benefit, reciprocity and common development. As B50AH1000 Mechanical and B50AH1000 suppliers, we can supply B50AH1000 Chemical, B50AH1000 Mechanical and B50AH1000 standard for you ,please contact us.
