DC04 cold rolled coils

DC04 cold rolled coils

DC04 cold-rolled steel sheet is mainly used for deep drawing and shaping process.

DC04 cold-rolled steel sheet mechanical properties:

Grade

MPa
Yield strength

MPa
Tensile strength
Not less than

Elongation % A80mm not less than



r90°

n90°

mm nominal thickness

<0.30

0.30~<0.50

0.50~<0.70

0.70~<1.0

1.0~<1.6

≧1.6

Not less than

DC04

130~210

270

_

34

36

38

39

40

1.6

0.18

a. when there is no significant yield, RP0.2 should be used; otherwise ReL should be used. When the thickness is more than 0.50mm and not more than 0.70mm, the specified value of the yield strength is allowed to increase 20MPa; when the thickness is not more than 0.50mm, the specified value of the yield strength is allowed to increase 40MPa.
b. The sample is the P6 sample in GB/T 228 and the sample direction is transverse.
c. The requirement of r90 and n90 values apply only to products with the thickness not less than 0.50mm. When the the thickness is more than 2.00mm, the value of r90 is allowed to lower 0.2.

Available range of DC04 cold-rolled steel sheet for appliances:

Item

Nominal size

Thickness

0.25-3.5

Width

800-1830

Length

Steel plate

1000-6000

Steel strip

Coil inside diameter 508,610

China special steel limited can provide six grades of DC series for appliances, they are DC01, DC04, DC04, DC05, DC06, DC07. Welcome to our website www.hastelloy-c276.com to get more details, or you can directly contact our salesmen.
