With general use, and pure zinc coating, DC04E+Z electrogalvanized plates and strips provided by China special steel limited are featured with good erosion-resistant, high surface quality (O5 plate surfaces are available) and excellent processing and coating performances. They can be used to manufacture inside and outside plates for home appliances.
Available range of DC04E+Z electro-galvanized steel sheets for appliances:
Item |
Nominal |
|
Thickness |
0.3-3.5 |
|
Width |
800-1830 |
|
Length |
Steel plate |
1000-6000 |
Steel strip |
Coil inside diameter 508,610 |
DC04E+Z electro-galvanized coating range and recommended nominal coating weight:
|
Coating type |
|
Pure zinc coating (single-side) g/m² |
Zinc-nickel alloy coating (single-side) g/m² |
|
Uniform thickness |
3~90 |
10~40 |
Different thickness |
3~90, the maximum difference value between both sides is 40. |
10~40, the maximum difference value between both sides is 20. |
Single side |
10~110 |
10~40 |
Note: The weight of 50g/m²of pure zinc coating is equal to about 7.1um, and the weight of 50g/m² of zinc-nickel alloy coating is equal to about 6.8um. |
Coating form |
Coating type |
|
|
Pure zinc coating (single-side) g/m² |
Zinc-nickel alloy coating (single-side) g/m² |
Uniform thickness |
10/10, 20/20, 30/30, 40/40, 50/50, 70/70, 90/90 |
10/10, 20/20, 30/30, 40/40 |
Difference thickness |
10/30, 20/40, 30/50, 40/60, 50/70, 60/90 |
10/20, 15/25, 25/30, 30/40 |
Single side |
10/0, 20/0, 30/0, 40/0, 50/0, 60/0, 70/0, 80/0, 90/0, 100/0, 110/0 |
10, 15, 20, 25, 30, 40 |
If you want to purchase electro-galvanized steel sheet for appliances, just login into China special steel limited 's website www.hastelloy-c276.com to get more details, and contact our slaesmen.
