DC51D+AZ cold rolled coils

55% Al-Zn alloy coated steel sheet has excellent weather-proof property and appearance. In addition to the plate for top grade building outside, the volume of 55% Al-Zn alloy coated sheet with Cr-free passivation and anti-fingerprinting treatment used in home appliaance is getting bigger and bigger.

DC51D+AZ 55% AI-Zn alloy galvanized steel sheet for appliances is mainly used for cold forming. With 55% Al-Zn alloy galvanized coating, the Recommended nominal coating weight is 30/30，40/40，50/50，60/60，75/75，90/90g/m².

DC51D+AZ hot dip galvanized automotive steel mechanical performances and coating adhesiveness:

Steel grade	Mechanical performances						Coating adhesiveness
	Yield strength MPa	Tensile strength MPa	n90 ≥	r=90 ≥	After breakage percent elongation % ≥		Bending center diameter in following coating weight(g/m²）c (a=plate thickness)
					L0=80mm, b=20mm		≤140/140	> 140/140~175/175	> 175/175
					Under following nominal thickness mm
					≤0.7	> 0.7
DC51D+AZ	-	270~500	-	-	20	22	0a	1a	2a

Allowable reduction of min.r90 specified is by 0.2 in case of product thickness > 1.5mm.
Allowable reduction of min.r90 and n90 specified are respectively by 0.2 and 0.01 in case of product thickness<0.7mm.
For differential coated products, the thicker coating is used as outside surface in bending test.

DC51D+AZ hot dip galvanized automotive steel coating weight range:

Coating form	Applicable surface structure	Weight range of following coatings a g/m
Coating form	Applicable surface structure	Zinc coating	Zn-Fe alloy coating
Equally coating	Z, X, G, GX, N, R	40/40~225/225	30/30~90/90
Differential coating b	N, R	30~150(each side)	-
a. 50 g/m coating weight is equivalent to about 7.1 b. max. differential coating thickness ration is 1:3.
