BW400 hot rolled coils

BW400 steel are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outsanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality.

BW400 steel size

Grade	Thickness mm	Width mm	Length mm
BW400	3-12	850-1800	2000-12000

BW400 steel sheet Chemical Composition wt%

Grade	C≤	Si≤	Mn≤	P≤	S≤	Alt≤	Cr≤	Ni≤	Ti	B≤
BW400	0.30	0.70	1.60	0.020	0.010	0.015	1.00	0.70	0.05	0.005

CEV = C + Mn/6 + Cr/5 + Mo/5 + B/5 + Cu/15 + Ni/15

BW400 steel plate Mechanical Properties

Grade

Thickness

(mm)

Tensile test

Brinell hardness

Impact energy

90° bending

Yield strength ReH,MPa

Tensile strength Rm,MPa

Elongation A50 %

HBW

Impact energy
-40℃
KV2,J

Bending diameter

BW400

3-12

≥960

≥1200

≥8

400±30

≥20

d = 6a

Note : Transversal specimen is adopted in the tensile test, thus the long axis of specimen is vertical to rolling direction.
ongitudinal specimen is used in impact test, and the impact value is obtained from standard specimen (10 × 10 × 50mm); The impact value shall be reduced with equal proportion if the smaller sized specimen is used, such as 5mm,7.5mm.
Transversal specimen is used in the bending test. d=bending diameter，a=plate thickness

BW400 steel plate/sheet Typical Properties

Parameter	Unit	BW400
CEV(IIW)	%	0.43
Welding crack sensitivity index Pcm	%	0.25
Yield Strength Re	MPa	1190
tensile strength Rm	MPa	1400
Elongation A5 0	%	12
Impact energy （-40℃） KV2	J	80
HBW	HBW	400
90° bending		D=6t
Young’s modulus(20℃)	GPa	210
Shear modulus(20℃)	GPa	80.8
Poisson ratio(20℃~40℃)	---	0.29
Density	g/cm3	7.85
Thermal conductivity (25℃)	W/(m.K)	48.54
Thermal expansivity(25℃)	1/K	1.254×10-5
比热Specific heat (25℃)	j/(kg.K)	451.89

The wear test result of BW400 plate (8mm in thickenss )

Grade	Weight loss, mg				Loss ration,mg/m
	1	2	3	Average	1	2	3	Average
BW400	127.90	101.40	96.85	108.72	14.21	11.27	10.76	12.08
Contrast steel	128.55	133.35	122.10	128.00	14.28	14.28	13.57	14.22

BW400 steel application :
BW400 steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain , cement, grabbucket, etc.
