Hastelloy C-22 Wrought nickel-base superalloy

Hastelloy C-22 Wrought nickel-base superalloy

Hastelloy C-22 Wrought nickel-base superalloy

Hastelloy C-22 alloy steel is a omnipotent, nickel-chromium-molybdenum-tungsten alloy than other existing nickel chromium molybdenum alloy has better overall corrosion resistance, including Hastelloy C276, C4 alloy and 625 alloy. Hastelloy C22 alloy has good resistance to pitting corrosion, crevice corrosion and stress corrosion cracking ability. It has excellent antioxidant ability to water medium, including wet chlorine, nitric acid or oxidizing acid containing chloride ions mixed acid. At the same time, Hastelloy C22 alloy also has the ideal resistance encountered in the process of reducing and oxidizing environment. Rely on the universal performance, it can be used in some headache environment, or used in a variety of factory production purpose. Hastelloy C22 alloy has abnormal resistance of variouschemical environment, including strong oxidizing substances, such as ferric chloride, copper chloride, chlorine, thermal pollution solution (organic, inorganic), formic acid, acetic acid, acetic anhydride, water and salt solution, etc. Hastelloy C22 alloy in welding heat affected zone is to resist the ability of grain boundary precipitation formation, so make it under welding condition also can adapt many kinds of the application of chemical process.

1. Hastelloy C-22 equal material :UNS N06022 (America), W.Nr.2.4602(Germany), NS3308(Chinese)

2. Hastelloy C-22 Wrought nickel-base superalloy Chemical composition %

HastelloyC22

Ni
Cr
Mo
Te
W
Co
C
Mn
Si
V
P
S
Mix
Remaining
20.0
12.5
2
2.5







Max
22.5
14.5
6
3.5
2.5
0.015
0.5
0.08
0.35
0.02
0.02

3. Hastelloy C - 22 Wrought nickel-base superalloy the mechanical properties at room temperature, the minimum value:

Material Tensile strength Yield strength Elongation A5 %
Hastelloy C22
690 MPa
283 MPa
40

4. Hastelloy C-22 The physical and chemical properties :
Hastelloy C – 22 alloy steel Density: 8.69 g/cm3
Hastelloy C-22 alloy steel melting point: 1357-1399 degree
Hastelloy C-22 Elastic modulus: N/thermal conductivity was 205.5:11.1 W/m K
Hastelloy C-22 Hardness: HRC93 thermal expansion coefficient (20-100 degree) : 112.6 mu m/m degree
Hastelloy C-22 Working temperature of about quantity: 200 to + 400 degree

5. Hastelloy C-22 Wrought nickel-base superalloy application:
The acetic acid/acetic anhydride, Acid leaching, The glassine paper manufacturing, The chloride system, Complex mixed acid,
Electric galvanized trough roller, Bellows expansion, The flue gas cleaning system, Geothermal Wells, Hf furnace cleaners,
The burning system, The fuel, The pesticide production, Phosphoric acid production, Pickling system, The plate heat exchanger,
Selective filtering system, Sulfur dioxide cooling tower, The suffocated system,Tube heat exchanger.
