UNS N06022 Wrought nickel-base super alloy

UNS N06022 alloy is a omnipotent, nickel-chromium-molybdenum-tungsten alloy than other existing nickel chromium molybdenum alloy has better overall corrosion resistance, including Hastelloy C276, C4 alloy and 625 alloy. UNS N06022 alloy has good resistance to pitting corrosion, crevice corrosion and stress corrosion cracking ability. It has excellent antioxidant ability to water medium, including wet chlorine, nitric acid or oxidizing acid containing chloride ions mixed acid. At the same time, UNS N06022 alloy also has the ideal resistance encountered in the process of reducing and oxidizing environment. Rely on the universal performance, it can be used in some headache environment, or used in a variety of factory production purpose. UNS N06022 alloy has abnormal resistance of various chemical environment, including strong oxidizing substances, such as ferric chloride, copper chloride, chlorine, thermal pollution solution (organic, inorganic), formic acid, acetic acid, acetic anhydride, water and salt solution, etc. UNS N06022 alloy in welding heat affected zone is to resist the ability of grain boundary precipitation formation, so make it under welding condition also can adapt many kinds of the application of chemical process.

1. UNS N06022 equal material :W.Nr.2.4602(Germany), NS3308(Chinese)，Hastelloy C-22
2. UNS N06022 Wrought nickel-base superalloy Chemical composition %

UNS N06022		Ni	Cr	Mo	Te	W	Co	C	Mn	Si	V	P	S
	Mix	Remaining	20.0	12.5	2	2.5
	Max	Remaining	22.5	14.5	6	3.5	2.5	0.015	0.5	0.08	0.35	0.02	0.02

3. UNS N06022 Wrought nickel-base superalloy the mechanical properties at room temperature, the minimum value:

Material	Tensile strength	Yield strength	Elongation A5 %
UNS N06022	690 MPa	283 MPa	40

4. UNS N06022 The physical and chemical properties :
UNS N06022 alloy steel Density: 8.69 g/cm3
UNS N06022 alloy steel melting point: 1357-1399 degree
UNS N06022 Elastic modulus: N/thermal conductivity was 205.5:11.1 W/m K
UNS N06022 Hardness: HRC93 thermal expansion coefficient (20-100 degree) : 112.6 mu m/m degree
UNS N06022 Working temperature of about quantity: 200 to + 400 degree
5.UNS N06022 Wrought nickel-base superalloy application:
The acetic acid/acetic anhydride, Acid leaching, The glassine paper manufacturing, The chloride system, Complex mixed acid, Electric galvanized trough roller, Bellows expansion, The flue gas cleaning system, Geothermal Wells, Hf furnace cleaners, The burning system, The fuel, The pesticide production, Phosphoric acid production, Pickling system, The plate heat exchanger, Selective filtering system, Sulfur dioxide cooling tower, The suffocated system,Tub heat exchanger.
