Hastelloy X Wrought nickel-base superalloy

Hastelloy X Wrought nickel-base superalloy
Hastelloy X is a kind nickel base super alloy with Cr and Mo solid solution having a high iron content, strengthening,has good anti raising and corrosion resistance, moderate endurance and creep strength at 900 degree, cold, hot workability and good welding performance. The combustion chamber components used in the manufacture of aircraft engines and other high temperature components, long-term use under 900 degree, short-time working temperature can reach 1080 degree. The main varieties of supply of sheet, strip, pipe, bars, forgings, rings and precision casting.

1. Hastelloy X alloy equal material:
GH3536/GH536/GH22/GH334/GH739/SG-5(China), UNS NO6002, NC22FeD(France), NiCr22FeMo(Germany), Nimonic PE13(British)

Hastelloy X Wrought nickel-base superalloy Chemical composition

No more than

0.05- 0.15

20.5- 23.0

balance

0.50- 2.50

0.20- 1.00

8.0- 10.0

≤0.50

≤0.15

17.0- 20.0

0.010

0.50

1.00

0.025

0.015

3. Hastelloy X material Heat treatment system
Sheet and pipe: 1130 - 1170 degree, fast air cooling or water cooling;
Bar and ring pieces : 1175±15 degree , air cooling or faster cooling;
Strip: 1065 - 1105 degree , fast cooling.

4. Hastelloy X alloy steel supply specifications
Sheet : thickness 0.5 ~ 4.0 mm
Strip : thickness 0.05 ~ 0.8 mm
Pipe: 4 - 20 mm outside diameter, wall thickness of 1.0 ~ 2.0 mm
Wire: diameter 0.2 ~ 10.0 mm
Bar: diameter 300 mm or less
Ring: all kinds of diameter and wall thickness and the precision casting of different shapes and sizes

5. Hastelloy X alloy steel supply Condition:
Sheet, strip and tubes : after solid solution treatment and acid cleaning
Strip : in cold rolling state
Welding wire: before hard and half hard, solid fusion and pickling, light solid solution treatment status in coil delivery, also can direct the delivery
Bar and annular parts: without heat treatment delivery
Precision casting : supply in casting state

6. Hastelloy X alloy steel application and special requirements
Hastelloy X alloy mainly used in the manufacture of hot end of combustion chamber parts and other components,and honeycomb structure, etc. Alloy at high temperature after long-term use of certain age hardening phenomenon.

7. Hastelloy X physical properties
Hastelloy X Melting temperature range: 1295-1381 degree.
Hastelloy X Density: 8.28g/cm3.

8.Hastelloy X Mechanical property:

Product	Room temperature			815degree Persistent property			Other properties
	Yield strength/MPa	Tensile strength/MPa	elongation δ5/%	σ/MPa	t/h	δ5/%
	no less than
Cold rolled sheet Cold rolled strip Cold drawn pipe bar Ring a casting	310 310 310 275 275 200	725 760 690 690 690 380	35 30 25 30 30 10	110 - - 105 105 -	24 - - 24 24 -	8.0 - - 10.0 10.0 -	bending 180° bending 180° Hydraulic, flaring HBS≤241 HBS≤241 HBS≤96
