High temperature high strength alloy steel W.Nr.1.4959
W.Nr.1.4959 is a fully austenitic low-carbon nickel - iron - chromium alloy in the same series of With W.Nr.1.4959 the cobalt content of alloy can be strictly controlled under 0.01%. W.Nr.1.4959 ability a lot of corrosion medium corrosion. Its high content of nickel in the aqueous corrosion condition has the very good resistance to stress corrosion cracking performance. W.Nr.1.4959 alloy steel usually applied in nitric acid condenser, nitric acid corrosion resistance, steam heating pipe and so one which request 500 degree working environment. W.Nr.1.4959 alloy steel usually be delivered with annealed state.
1. W.Nr.1.4959equal material: W.Nr.1.4876, X10NiCrAlTi3220, NA15, UNS N08811, FeNi32Cr21AlTi, X 8 NiCrAlTi 32-21, Incoloy 800, Z8NC32.21
% | Ni | Cr | Fe | Mo | Co | C | Mn | Si | S | P | Cu | Al | Ti |
min | 30.0 | 19.0 | 0.06 | 0.15 | 0.15 | ||||||||
max | 35.0 | 23.0 | 39.5 | 0.1 | 1.5 | 1.0 | 0.015 | 0.75 | 0.60 | 0.60 |
3. W.Nr.1.4959 Physical properties :
W.Nr.1.4959 alloy steel Density: 8.0g/cm3
W.Nr.1.4959 alloy steel Melting temperature range :1350-1400 degree
4. W.Nr.1.4959 Mechanical properties at room temperature (minimum)
W.Nr.1.4959alloy steel product | specifications | yield strength RP0.2 N/mm2 | yield strength RP1.0 N/mm2 | Tensile strength Rm N/mm2 | elongation A50% | hardness HB |
cold rolling strip hot rolled plate | 0.5-6.4 | 240 | 265 | 585 | 30 | <=200 |
5-100 | 135-165 | |||||
bar Cold working Hot working | 1.6-64 | |||||
25-100 | ||||||
>100-240 | 220 | 250 | 550 | 35 | ||
pipe Cold working Hot working | 64-240 | 180 | - | 530 | 30 | - |
5-100 | 240 | 265 | 585 | 30 | ||
Condensation and heat exchanger | 16-76 |
5. Application: W.Nr.1.4959 alloy steel are widely used in various industrial sectors whose working temperature does not exceed 550 degree. Typical applications are:
sulfuric acid pickling factories with the heating pipe, containers, baskets, and chain, etc.
water cooling heat exchanger, Marine products pipeline system, acidic gas pipeline environment. heat exchanger in phosphoric acid production, evaporator, washing, dip tube, etc.
