UNS N05500

N05500 Equal material : Monle K-500

N05500 Characteristic:
N05500 is also called UNS N05500, and Alloy with 400 identical corrosion resistance, but has higher mechanical strength and hardness. N05500 alloy steel Has good heat resistance and long term stability.

N05500 Corrosion resistant alloy application field :Mainly used in the manufacture of aviation engine operating temperature at turbine vane and turbine blade under 750 degree ; used for fasteners, spring manufacturing ship pump, valve parts; chemical equipment; papermaking equipment the pulp scraping blade.

N05500 alloy can make plates, steel sheet, forging,round steel, alloy wire

N05500 alloy Chemical composition：

	Ni	Fe	C	Mn	Si	Ti	Cu	Al	S
Min	63					0.35	27.0	2.30
Max		2.0	0.25	1.5	0.5	0.85	33.0	3.15	0.01

N05500 physical property ：
N05500 alloy density: 8.05g/cm3
N05500 alloy steel Melting temperature range: 1288-1343 degree

N05500 alloy minimum mechanical properties value at room temperature :

Alloy	Tensile strength MPa	Yield strength MPa	Elongation A5 %
N05500	1100	790	20

N05500 alloy steel apply range：
Aviation, shipbuilding, chemical equipment
