ZbNCT25iron-based wrought superalloy

ZbNCT25iron-based wrought superalloy
ZbNCT25 is A Fe - ni - cr 15 25 based high temperature alloy, molybdenum, titanium, aluminum, vanadium and trace boron composite reinforcement.Under 650 degree has high yield strength and lasting and creep strength, and has good processing plastic and satisfactory welding performance.Suitable for manufacturing in the long term work of aircraft engine under 650 degree high temperature bearing parts, such as turbine disc, press plate, the rotor blades and fasteners, etc.Can produce all kinds of deformation in the shape of the alloy products, such as plate, forgings, plate, bar, wire and circular pieces, etc.
High-quality ZbNCT25 alloy, which is on the basis of ZbNCT25 alloy development, as long as is to improve the alloy purity, gas content, control the
content of low melting point elements, and adjust the system of heat treatment, so that the alloy heat intensity and the long-term use of performance improvement.
1.ZbNCT25 steel equal material : A286,UNSS66286,P.Q.A286, Incoloy A - 286
2.ZbNCT25 alloy chemical composition %

≤0.08

13.5- 16.0

24.0- 27.0

1.00- 1.50

1.75- 2.30

0.10- 0.50

0.001-0.010

1.00- 2.00

≤0.04

≤1.00

≤0.030

≤0.020

remaining

Note: ZbNCT25Cold drawing steel rods, ZbNCT25steel disc and ZbNCT25steel ring standard rules (Ti)1.80%-2.35%。
ZbNCT25Hot rolled steel sheet and ZbNCT25cold rolled steel sheet standard requirements (B)0.003%-0.010%, (Mn)≤2.00%, (P)≤0.020%, (S)≤0.015%。
ZbNCT25Cold drawn wire standard request (Al)≤0.35%, (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.020%, (S)≤0.015%。
ZbNCT25Cold heading with silk material standards request: (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.025%, (S)≤0.020%。
ZbNCT25Hot rolled and forged bar standard request (Cu)≤0.25%。
High-quality Incoloy A - 286 alloy chemical composition %

C	Cr		Ni		Mo		Ti	Fe		V		B		Mn		Al	Si		P		S
														≤
≤0.08	13.50-16.00		24.00-27.00		1.00- 1.50		1.90- 2.35	remaining		0.10-0.50		0.003-0.010		0.35		0.35	0.35		0.015		0.002
Ca		Mg		Cu			Sn	Pb	Se		Ag		Te		Tl	Bi		N		O
≤
0.005		0.005		0.30		0.0050		0.0005	0.0003		0.0005		0.00005		0.0001	0.00003		0.0100		0.0050

3. ZbNCT25Heat treatment system are shown in the following table. Quality Incoloy A - 286 heat treatment is at 900 degree plus or minus 10 degree, 1 ~ 2 h, oil cooled to + 750 degree + 10 degree, 16 h, air cooling.< br>

Product	Heat treatment system
ZbNCT25 Rod bar, disc	980-1000 degree,1-2h, Oil cooling＋700-720 degree, 12-16h, Air cooling
ZbNCT25 Hot rolled / cold rolled plates	980-1000 degree, Air cooling＋700-720degree, 12-16h, Air cooling
ZbNCT25 Cold drawn rod	980-1000 degree,1-2h,Oil cooling＋700-720℃,16h, Air cooling
ZbNCT25 Ring	980-990 degree 1-2h, Oil cooling＋700-720degree, 16h, Air cooling
ZbNCT25 cold drawing wire	980-1000degree, Water cooling or Oil cooling＋700-720 degree,16h, Air cooling
