Incoloy A-286 iron-based wrought superalloy steel

Incoloy A-286 iron-based wrought superalloy

Incoloy A- 286 is A Fe - ni - cr 15 25 based high temperature alloy, molybdenum, titanium, aluminum, vanadium and trace boron composite reinforcement. Under 650 degree has high yield strength and lasting and creep strength, and has good processing plastic and satisfactory
welding performance. Suitable for manufacturing in the long-term work of aircraft engine under 650 degree high temperature bearing parts, such as turbine disc, press plate, the rotor blades and fasteners,etc. Can produce all kinds of deformation in the shape of the alloy products, such as plate, forgings, plate, bar, wire and circular pieces, etc.High-quality Incoloy A - 286 alloy, which is on the basis of Incoloy A - 286 alloy development, as long as is to improve the alloy purity, gas content, control the content of low melting point elements, and adjust the system of heat treatment, so that the alloy heat intensity and the long-term use of performance improvement.

1. Incoloy A - 286 steel equal material : A286,UNSS66286,P.Q.A286, ZbNCT25

2. Incoloy A - 286 alloy chemical composition %

≤0.08

13.5- 16.0

24.0- 27.0

1.00- 1.50

1.75- 2.30

0.10- 0.50

0.001-0.010

1.00- 2.00

≤0.04

≤1.00

≤0.030

≤0.020

remaining

Note: Incoloy A-286 Cold drawing steel rods, Incoloy A-286 steel disc and Incoloy A-286 steel ring standard rules(Ti)1.80%-2.35%。
Incoloy A-286 Hot rolled steel sheet and Incoloy A-286 cold rolled steel sheet standard requirements(B)0.003%-0.010%, (Mn)≤2.00%, (P)≤0.020%, (S)≤0.015%。
Incoloy A-286 Cold drawn wire standard request (Al)≤0.35%, (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.020%, (S)≤0.015%。
Incoloy A-286 Cold heading with silk material standards request: (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.025%, (S)≤0.020%。
Incoloy A-286 Hot rolled and forged bar standard request (Cu)≤0.25%.

High-quality Incoloy A - 286 alloy chemical composition %

C	Cr		Ni		Mo		Ti	Fe		V		B		Mn		Al	Si		P		S
														≤
≤0.08	13.50-16.00		24.00-27.00		1.00- 1.50		1.90- 2.35	remaining		0.10-0.50		0.003-0.010		0.35		0.35	0.35		0.015		0.002
Ca		Mg		Cu			Sn	Pb	Se		Ag		Te		Tl	Bi		N		O
≤
0.005		0.005		0.30		0.0050		0.0005	0.0003		0.0005		0.00005		0.0001	0.00003		0.0100		0.0050

3. Incoloy A-286 Heat treatment system are shown in the following table. Quality Incoloy A - 286 heat treatment is at 900 degree plus or minus 10 degree, 1 ~ 2 h, oil cooled to + 750 degree + 10 degree, 16 h, air cooling.

Product	Heat treatment system
Incoloy A - 286 Rod bar, disc	980-1000 degree,1-2h, Oil cooling＋700-720 degree, 12-16h, Air cooling
Incoloy A - 286 Hot rolled / cold rolled plates	980-1000 degree, Air cooling＋700-720degree, 12-16h, Air cooling
Incoloy A - 286 Cold drawn rod	980-1000 degree,1-2h,Oil cooling＋700-720℃,16h, Air cooling
Incoloy A - 286 Ring	980-990 degree 1-2h, Oil cooling＋700-720degree, 16h, Air cooling
Incoloy A - 286 cold drawing wire	980-1000degree, Water cooling or Oil cooling＋700-720 degree,16h, Air cooling
