BW500 hot rolled coils

BW500 B : China special steel limited,W : Wear Resistant Steel,500：Brinell hardness value

BW500 steel are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outsanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality.

BW500 steel Chemical Composition wt%

Grade	C≤	Si≤	Mn≤	P≤	S≤	Alt≤	Cr≤	Ni≤	Ti	B≤	CEV
BW500	0.38	0.70	1.60	0.020	0.010	0.015	1.20	0.80	0.05	0.005	0.55

CEV = C + Mn/6 + Cr/5 + Mo/5 + B/5 + Cu/15 + Ni/15

BW500 steel sheet Mechanical Properties

Grade

Thickness

(mm)

Tensile test

Brinell hardness

Impact energy

90° bending

Yield strength ReH,MPa

Tensile strength Rm,MPa

Elongation A50 %

HBW

Impact energy
-40℃
KV2,J

Bending diameter

BW500

3-12

---

500±30

≥20

d = 8a

Note : Transversal specimen is adopted in the tensile test, thus the long axis of specimen is vertical to rolling direction.
ongitudinal specimen is used in impact test, and the impact value is obtained from standard specimen (10 × 10 × 50mm); The impact value shall be reduced with equal proportion if the smaller sized specimen is used, such as 5mm,7.5mm.
Transversal specimen is used in the bending test. d=bending diameter，a=plate thickness

BW500 steel plate size

Grade	Thickness mm	Width mm	Length mm
BW500	3-12	950-1800	2000-12000

BW500 steel application :
BW500 steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain , cement, grabbucket, etc.

China special steel limited Will return you with high-quality products and complete after-sale service with the lowest price. we committed to exceed customer's expectation on the basis of quality, price, and delivery. We sincerely hope to establish long-term cooperation relationship with you on the basis of mutual benefit, reciprocity and common development. As BW500 Mechanical and BW500 suppliers, we can supply BW500 Chemical, BW500 Mechanical and BW500 standard for you ,please contact us.
