GH145 Wrought nickel-base superalloy

GH145 Wrought nickel-base superalloy

GH145 Wrought nickel-base superalloy

GH145 Alloy steel is mainly by γ [Ni3 (Al, Ti, Nb)] phase of nickel base superalloy aging strengthening, has good corrosion resistance and oxidation resistance at 980 degree, 800 degree with higher intensity, 540 degree with relaxation has good performance, but also has the forming and welding performance good. This alloy is mainly used in the manufacture of aero engine under 800 degree and requirements and high strength corrosion resistant ring parts, structural parts and bolts and other components, in 540 degree work with medium or low stress and resistance to planar spring relaxation and spiral spring. Also can be used in the manufacture of gas turbine blades. Can supply a variety of sheet, strip, bars, forgings, ring, wires and tubes.

1. GH145 Wrounght nickel-base superalloy equal material : GH4145, NiCr15Fe7TiAl, NC15FeTNbA, NCF750

2. GH145 Alloy steel Chemical composition

C Cr Ni+Co Al Ti Fe Nb+Ta Co Mn Si S Cu P
≤
≤0.08 14.0-17.0 ≥70.0 0.40-1.00 2.25-2.75 5.00-9.00 0.70-1.20 1.00 1.00 0.50 0.010 0.50 0.015

3. GH145Alloy steel physical properties
GH145Alloy steel The melting temperature range 1395-1425 degree.
GH145Alloy steel Density : 8.25g/cm3

4. GH145 alloy steel Mechanical properties
Product Tensile strength /MPa Yield strength MPa Elongation /% HRC
GH145 Alloy steel Strip ≤930 - ≥18 -
≥1105 - ≥12 ≥30
GH145 Alloy cold rolled steel sheet ≤930 ≤515 ≥30 -
≤930 ≤515 ≥35 -
GH145 Alloy hot rooled steel plate ≥1170 ≥795 ≥18 ≥32
GH145Alloy steel tube ≤965 ≤550 ≥35 -
≥1170 ≥790 ≥15 -
