NCF750 Wrought nickel-base superalloy

NCF750 Wrought nickel-base superalloy

NCF750 Wrought nickel-base superalloy

NCF750 Alloy steel is mainly by γ [Ni3 (Al, Ti, Nb)] phase of nickel base superalloy aging strengthening, has good corrosion resistance and oxidation resistance at 980 degree, 800 degree with higher intensity, 540 degree with relaxation has good performance, but also has the forming and welding performance good. This alloy is mainly used in the manufacture of aero engine under 800 degree and requirements and high strength corrosion resistant ring parts, structural parts and bolts and other components, in 540 degree work with medium or low stress and resistance to planar spring relaxation and spiral spring. Also can be used in the manufacture of gas turbine blades. Can supply a variety of sheet, strip, bars, forgings, ring, wires and tubes.

1. NCF750Wrounght nickel-base superalloy equal material :GH145, NiCr15Fe7TiAl, NCF750
2. NCF750 Alloy steel Chemical composition

C Cr Ni+Co Al Ti Fe Nb+Ta Co Mn Si S Cu P
≤
≤0.08 14.0-17.0 ≥70.0 0.40-1.00 2.25-2.75 5.00-9.00 0.70-1.20 1.00 1.00 0.50 0.010 0.50 0.015

3. NCF750Alloy steel physical properties
NCF750Alloy steel The melting temperature range 1395-1425 degree.
NCF750Alloy steel Density : 8.25g/cm3

4. NCF750 alloy steel Mechanical properties

Product Tensile strength /MPa Yield strength MPa Elongation /% HRC
NCF750 Alloy steel Strip ≤930 - ≥18 -
≥1105 - ≥12 ≥30
NCF750 Alloy cold rolled steel sheet ≤930 ≤515 ≥30 -
≤930 ≤515 ≥35 -
NCF750 Alloy hot rooled steel plate ≥1170 ≥795 ≥18 ≥32
NCF750 Alloy steel tube ≤965 ≤550 ≥35 -
≥1170 ≥790 ≥15 -
