NiCrl5Fe

Product:NiCrl 5Fe The early development of Ni Cr Fe based solid solution strengthened alloys, has good resistance to high temperature corrosion and oxidation resistance, hot and cold processing quality and welding performance is satisfactory, heat resistance and high plasticity at 700 degree. Alloy can be enhanced by cold working, can also be connected with the resistance welding, welding or soldering solution, which can supply cold rolled sheet, hot-rolled plate, strip, wire, bar, pie, the ring blank, forging ring, suitable for making under low load of antioxidant components in 1100 degree .

NiCrl 5Fe equal material : Inconel600, GH600/GH3600

NiCrl 5Fe chemical composition %

C	Cr	Ni+Co	Al	Ti	Fe	Nb+Ta	Mn	Si	P	S	Cu
≤0.15	14.0-17.0	≥72	≤0.35	≤0.50	6.00～10.00	≤1.00	≤1.00	≤0.50	≤0.040	≤0.015	≤0.50

Heat treatment

Product	Heat treatment system
NiCrl 5Fe steel plate	1010-1050 degree,3-5 min/mm, Air cooling
NiCrl 5Fe steel strip	1010±10 degree, Air cooling
NiCrl 5Fe wire	1065±10 degree, Air cooling
NiCrl 5Fe Ring and Rod	1010±10 degree, Air cooling

NiCrl 5Fe nickel-base superalloy melting and casting process:
(1) non vacuum induction melting and electroslag remelting;
(2) electric arc furnace melting and electroslag remelting;
(3) the vacuum melting.
5.NiCrl 5Fe The physical and chemical properties.
NiCrl 5Fe steel melting temperature 1370-1430 degree
NiCrl 5Fe density : 8.43g/cm3
NiCrl 5Fe mechanical property

Product	θ/℃	Tensile property				HBS	Bending test
Product	θ/℃	σb/MPa	σP0.2/MPa	δ5/%	φ/%	HBS	Bending test
NiCrl 5Fe steel bar	20	≥585	≥240	≥30	-	134-217	-
NiCrl 5Fe steel ring, Cake or loop	20	≥520	≥205	≥35	-	≥187	-
NiCrl 5Fe steel Hot rolled plate	20	≥550	≥240	≥35	≥40	-	-
NiCrl 5Fe steel Hot rolled plate	900	≥95	≥45	≥40	≥50	-	-
NiCrl 5Fe steel Cold rolled plate	20	≥550	≥240	≥30	-	-
NiCrl 5Fe steel Cold rolled plate	900	≥90	≥40	≥60	-	-	-
Cold rolled plate	20	≥550	≥200	≥30	-	-	test
NiCrl 5Fe steel strip	20	≥550	≥240	≥30	-	-

NiCrl 5Fe alloy steel forming properties : has good processing performance, ingot forging heating temperature 1110 -1140 degree; the final forging temperature less than 950 degree, slab rolling heating temperature 1130 - 1170 degree, finishing the heating temperature is 1090 - 1130 degree. The finished product solid solution treatment temperature of 1010 -1050 degree.

NiCrl 5Fe alloy steel Good welding performance properties : welding, connection available electric arc welding, argon arc welding, resistance welding and brazing and other methods, large or complex welding pieces of the structure in the welding should be at 870 degree for 1h, to eliminate the welding stress.

NiCrl 5Fe alloy steel Heat treatment process : should be carried out according to the heat treatment system of the corresponding material standard. Annealed sheet and strip parts should be carried out in a protective atmosphere.
